881 M Flat Top

881 M Flat Top

	Width	Material	Part	Back flex radius	Sideflexing radius min	Mass	Surface finish	Surface Flatness	Polished Hinge	Pin material	Box	Max working load
Code	All K 325 - 82,5 mm K 330 - 83,8 mm K 450 - 114,3 mm K 750 - 190,5 mm	All SS - Ferritic Stainless Steel 1.4016 SSE - Specially treated Ferritic Stainless Steel 1.4589 SSM - Specially treated Ferritic SS 1.4589	All P1008	All 80 mm	All 500 mm	All 2.55 kg/m 2.59 kg/m 3.1 kg/m 4.85 kg/m	All 0.2 mm 0.3 mm 0.5 mm	All 0.08 mm 0.1 mm 0.15 mm 0.2 mm 0.3 mm	All Yes	All Martensitic 1,4057	All 10 ft - 3,048 m	All 5400 N 6000 N	Actions
P10080102	K 325 - 82,5 mm	SSE - Specially treated Ferritic Stainless Steel 1.4589	P1008	80 mm	500 mm	2.55 kg/m	0.3 mm	0.1 mm	Yes	Martensitic 1,4057	10 ft - 3,048 m	6000 N
P10080103	K 330 - 83,8 mm	SSE - Specially treated Ferritic Stainless Steel 1.4589	P1008	80 mm	500 mm	2.59 kg/m	0.3 mm	0.1 mm	Yes	Martensitic 1,4057	10 ft - 3,048 m	6000 N
P10080105	K 450 - 114,3 mm	SSE - Specially treated Ferritic Stainless Steel 1.4589	P1008	80 mm	500 mm	3.1 kg/m	0.3 mm	0.2 mm	Yes	Martensitic 1,4057	10 ft - 3,048 m	6000 N
P10080107	K 750 - 190,5 mm	SSE - Specially treated Ferritic Stainless Steel 1.4589	P1008	80 mm	500 mm	4.85 kg/m	0.3 mm	0.3 mm	Yes	Martensitic 1,4057	10 ft - 3,048 m	6000 N
P10080202	K 325 - 82,5 mm	SS - Ferritic Stainless Steel 1.4016	P1008	80 mm	500 mm	2.55 kg/m	0.5 mm	0.15 mm	Yes	Martensitic 1,4057	10 ft - 3,048 m	5400 N
P10080203	K 330 - 83,8 mm	SS - Ferritic Stainless Steel 1.4016	P1008	80 mm	500 mm	2.59 kg/m	0.5 mm	0.15 mm	Yes	Martensitic 1,4057	10 ft - 3,048 m	5400 N
P10080205	K 450 - 114,3 mm	SS - Ferritic Stainless Steel 1.4016	P1008	80 mm	500 mm	3.1 kg/m	0.5 mm	0.2 mm	Yes	Martensitic 1,4057	10 ft - 3,048 m	5400 N
P10080207	K 750 - 190,5 mm	SS - Ferritic Stainless Steel 1.4016	P1008	80 mm	500 mm	4.85 kg/m	0.5 mm	0.3 mm	Yes	Martensitic 1,4057	10 ft - 3,048 m	5400 N
P10080302	K 325 - 82,5 mm	SSM - Specially treated Ferritic SS 1.4589	P1008	80 mm	500 mm	2.55 kg/m	0.2 mm	0.08 mm	Yes	Martensitic 1,4057	10 ft - 3,048 m	6000 N
P10080303	K 330 - 83,8 mm	SSM - Specially treated Ferritic SS 1.4589	P1008	80 mm	500 mm	2.59 kg/m	0.2 mm	0.08 mm	Yes	Martensitic 1,4057	10 ft - 3,048 m	6000 N

•
