Home Curves & straight tracks Straight track Straight track 1873-1874 TAB

Straight track 1873-1874 TAB

Straight track

Enquire Now

Description

TAB type corner tracks are a more economical solution compared to magnetic curves. In those applications where cleaning and product support are less important, they can perfectly be used.

Basic features

Series:	1873-1874 TAB
Type:	Tab
Box:	-

Straight track 1873-1874 TAB

	Chain/Belt Width	Length	Total Height	Unit of measure	Tracks	Basic width	Total width	Material UP	UP Height	Shoe	Temperature range dry
Code												Actions
P79223010	K 325 (82,55 mm) - K 330 (83,82 mm)	2000 mm mm	35 mm	Ea	1	100 mm	100 mm	UHMW-PE Black	35 mm	Not included	-40÷80 °C
P79223010B	K 325 (82,55 mm) - K 330 (83,82 mm)	2000 mm mm	35 mm	Ea	1	100 mm	100 mm	BluLub	35 mm	Not included	-40÷50 °C
P79223010C	K 325 (82,55 mm) - K 330 (83,82 mm)	2000 mm mm	35 mm	Ea	1	100 mm	100 mm	UHMW-PE Abrasive	35 mm	Not included	-40÷80 °C
P79224010	K 450 (114,30 mm)	2000 mm mm	35 mm	Ea	1	130 mm	130 mm	UHMW-PE Black	35 mm	Not included	-40÷80 °C
P79224010B	K 450 (114,30 mm)	2000 mm mm	35 mm	Ea	1	130 mm	130 mm	BluLub	35 mm	Not included	-40÷50 °C
P79224010C	K 450 (114,30 mm)	2000 mm mm	35 mm	Ea	1	130 mm	130 mm	UHMW-PE Abrasive	35 mm	Not included	-40÷80 °C
P79225010	K 600 (152,40 mm)	2000 mm mm	35 mm	Ea	1	170 mm	170 mm	UHMW-PE Black	35 mm	Not included	-40÷80 °C
P79225010B	K 600 (152,40 mm)	2000 mm mm	35 mm	Ea	1	170 mm	170 mm	BluLub	35 mm	Not included	-40÷50 °C
P79225010C	K 600 (152,40 mm)	2000 mm mm	35 mm	Ea	1	170 mm	170 mm	UHMW-PE Abrasive	35 mm	Not included	-40÷80 °C
P79226010	K 750 (190,50 mm)	2000 mm mm	35 mm	Ea	1	200 mm	200 mm	UHMW-PE Black	35 mm	Not included	-40÷80 °C
P79226010B	K 750 (190,50 mm)	2000 mm mm	35 mm	Ea	1	200 mm	200 mm	BluLub	35 mm	Not included	-40÷50 °C
P79226010C	K 750 (190,50 mm)	2000 mm mm	35 mm	Ea	1	200 mm	200 mm	UHMW-PE Abrasive	35 mm	Not included	-40÷80 °C
P79227010	K1000 (254 mm)	2000 mm mm	35 mm	Ea	1	270 mm	270 mm	UHMW-PE Black	35 mm	Not included	-40÷80 °C
P79227010B	K1000 (254 mm)	2000 mm mm	35 mm	Ea	1	270 mm	270 mm	BluLub	35 mm	Not included	-40÷50 °C
P79227010C	K1000 (254 mm)	2000 mm mm	35 mm	Ea	1	270 mm	270 mm	UHMW-PE Abrasive	35 mm	Not included	-40÷80 °C
P79228010	K1200 (304,80 mm)	2000 mm mm	35 mm	Ea	1	320 mm	320 mm	UHMW-PE Black	35 mm	Not included	-40÷80 °C
P79228010B	K1200 (304,80 mm)	2000 mm mm	35 mm	Ea	1	320 mm	320 mm	BluLub	35 mm	Not included	-40÷50 °C
P79228010C	K1200 (304,80 mm)	2000 mm mm	35 mm	Ea	1	320 mm	320 mm	UHMW-PE Abrasive	35 mm	Not included	-40÷80 °C
