1873 TAB Gripper GS2

Plastic chains

Enquire Now

Description

Specifically developed to work with the entire 1873 Gripper plastic chain family, this roller chain delivers exceptional strength and durability, with a breaking load of 27.5 kN. The enhanced total elongation improves ductility, while outstanding resistance to cyclic stress ensures consistent performance in high-frequency applications. Controlled elastic behavior reduces impact on guides, sliders, and plastic components, extending the overall system’s lifespan. Muscle roller chain is engineered for frequent washdowns, high humidity, and thermal variations, and it’s ideal for critical industrial settings such as food processing and packaging. The special anti-corrosion coating ensures reliable operation even in the presence of moderate chemicals, delivering hygiene, effifficiency, and long-lasting performance. Muscle roller chain is also compatible with all Movex plastic chains with 19.05 mm pitch (3/4”, imperial standard) and equivalent dimensional characteristics.

Basic features

Series:	1843-1863-1873-1874-1883
Pitch:	38.1 mm
Thickness:	4 mm
Surface Type:	Gripper
Functionality:	Side Flex TAB
Unit of measure:	Meter

1873 TAB Gripper GS2

	Width	Material	Part	Back flex radius	Sideflexing radius min	Rubber type	Rubber color	Roller chain	Box	Max working load	Supplementary informations
Code												Actions
P11280102	K 325 - 82,5 mm	LFD - Low friction acetal (01)	P1128	150 mm	14.96 mm	TPR	Red	C45	10 ft - 3,048 m	4500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11280105	K 450 - 114,3 mm	LFD - Low friction acetal (01)	P1128	150 mm	14.96 mm	TPR	Red	C45	10 ft - 3,048 m	4500 N	-
P11280202	K 325 - 82,5 mm	LFD - Low friction acetal (01)	P1128	150 mm	14.96 mm	TPR	Red	Nickel Plated Steel	10 ft - 3,048 m	4500 N	-
P11280205	K 450 - 114,3 mm	LFD - Low friction acetal (01)	P1128	150 mm	14.96 mm	TPR	Red	Nickel Plated Steel	10 ft - 3,048 m	4500 N	-
P11280302	K 325 - 82,5 mm	LFD - Low friction acetal (01)	P1128	150 mm	14.96 mm	TPR	Red	Stainless Steel	10 ft - 3,048 m	3500 N	-
P11280302M	K 325 - 82,5 mm	LFD - Low friction acetal (01)	P1128	150 mm	14.96 mm	TPR	Red	MUSCLE Stainless Steel	10 ft - 3,048 m	3500 N	-
P11280305	K 450 - 114,3 mm	LFD - Low friction acetal (01)	P1128	150 mm	14.96 mm	TPR	Red	Stainless Steel	10 ft - 3,048 m	3500 N	-
P11280305M	K 450 - 114,3 mm	LFD - Low friction acetal (01)	P1128	150 mm	14.96 mm	TPR	Red	MUSCLE Stainless Steel	10 ft - 3,048 m	3500 N	-
P11290102	K 325 - 82,5 mm	PP - Polypropylene (02)	P1129	150 mm	14.96 mm	EPDM-PP	Black	C45	10 ft - 3,048 m	4500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11290105	K 450 - 114,3 mm	PP - Polypropylene (02)	P1129	150 mm	14.96 mm	EPDM-PP	Black	C45	10 ft - 3,048 m	4500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11290202	K 325 - 82,5 mm	PP - Polypropylene (02)	P1129	150 mm	14.96 mm	EPDM-PP	Black	Nickel Plated Steel	10 ft - 3,048 m	4500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11290205	K 450 - 114,3 mm	PP - Polypropylene (02)	P1129	150 mm	14.96 mm	EPDM-PP	Black	Nickel Plated Steel	10 ft - 3,048 m	4500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11290302	K 325 - 82,5 mm	PP - Polypropylene (02)	P1129	150 mm	14.96 mm	EPDM-PP	Black	Stainless Steel	10 ft - 3,048 m	3500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11290302M	K 325 - 82,5 mm	PP - Polypropylene (02)	P1129	150 mm	14.96 mm	EPDM-PP	Black	MUSCLE Stainless Steel	10 ft - 3,048 m	3500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11290305	K 450 - 114,3 mm	PP - Polypropylene (02)	P1129	150 mm	14.96 mm	EPDM-PP	Black	Stainless Steel	10 ft - 3,048 m	3500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11290305M	K 450 - 114,3 mm	PP - Polypropylene (02)	P1129	150 mm	14.96 mm	EPDM-PP	Black	MUSCLE Stainless Steel	10 ft - 3,048 m	3500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11340102	K 325 - 82,5 mm	MX - Performance PBT (03)	P1134	150 mm	14.96 mm	TPR	Red	C45	10 ft - 3,048 m	4500 N	-
P11340105	K 450 - 114,3 mm	MX - Performance PBT (03)	P1134	150 mm	14.96 mm	TPR	Red	C45	10 ft - 3,048 m	4500 N	-
P11340202	K 325 - 82,5 mm	MX - Performance PBT (03)	P1134	150 mm	14.96 mm	TPR	Red	Nickel Plated Steel	10 ft - 3,048 m	4500 N	-
P11340205	K 450 - 114,3 mm	MX - Performance PBT (03)	P1134	150 mm	14.96 mm	TPR	Red	Nickel Plated Steel	10 ft - 3,048 m	4500 N	-
P11340302	K 325 - 82,5 mm	MX - Performance PBT (03)	P1134	150 mm	14.96 mm	TPR	Red	Stainless Steel	10 ft - 3,048 m	3500 N	-
P11340302M	K 325 - 82,5 mm	MX - Performance PBT (03)	P1134	150 mm	14.96 mm	TPR	Red	MUSCLE Stainless Steel	10 ft - 3,048 m	3500 N	-
P11340305	K 450 - 114,3 mm	MX - Performance PBT (03)	P1134	150 mm	14.96 mm	TPR	Red	Stainless Steel	10 ft - 3,048 m	3500 N	-
P11340305M	K 450 - 114,3 mm	MX - Performance PBT (03)	P1134	150 mm	14.96 mm	TPR	Red	MUSCLE Stainless Steel	10 ft - 3,048 m	3500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11350102	K 325 - 82,5 mm	MWX - Polyamide Composite (17)	P1135	150 mm	14.96 mm	TPR	Red	C45	10 ft - 3,048 m	4500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11350105	K 450 - 114,3 mm	MWX - Polyamide Composite (17)	P1135	150 mm	14.96 mm	TPR	Red	C45	10 ft - 3,048 m	4500 N	Sprockets ANSI 60 - standard on Market Plate - AISI 420HT, Bushing - SINTERED, PIN - AISI 420HT, Roller - AISI 304 The rubber material complies with FDA regulations.
P11350202	K 325 - 82,5 mm	MWX - Polyamide Composite (17)	P1135	150 mm	14.96 mm	TPR	Red	Nickel Plated Steel	10 ft - 3,048 m	4500 N	Sprockets ANSI 60 - standard on Market Plate - AISI 420HT, Bushing - SINTERED, PIN - AISI 420HT, Roller - AISI 304 The rubber material complies with FDA regulations.
P11350205	K 450 - 114,3 mm	MWX - Polyamide Composite (17)	P1135	150 mm	14.96 mm	TPR	Red	Nickel Plated Steel	10 ft - 3,048 m	4500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11350302	K 325 - 82,5 mm	MWX - Polyamide Composite (17)	P1135	150 mm	14.96 mm	TPR	Red	Stainless Steel	10 ft - 3,048 m	3500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11350302M	K 325 - 82,5 mm	MWX - Polyamide Composite (17)	P1135	150 mm	14.96 mm	TPR	Red	MUSCLE Stainless Steel	10 ft - 3,048 m	3500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11350305	K 450 - 114,3 mm	MWX - Polyamide Composite (17)	P1135	150 mm	14.96 mm	TPR	Red	Stainless Steel	10 ft - 3,048 m	3500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
P11350305M	K 450 - 114,3 mm	MWX - Polyamide Composite (17)	P1135	150 mm	14.96 mm	TPR	Red	MUSCLE Stainless Steel	10 ft - 3,048 m	3500 N	Sprockets ANSI 60 - standard on Market The rubber material complies with FDA regulations.
