Zero Contact Hygienic
Zero Contact
Description
Description
Specifically designed for industrial environments with critical hygienic level, Zero Contact™ Hygienic is the perfect solutions for dairy, food, chemical and pharmaceutical industries, subjected to daily washing cycles.
Zero Contact™ Hygienic modular belt is approved for direct food contact by FDA.
Any bulk food product can stay on the modular belt without contamination.
With reference to the foodstuff categories detailed by Reg. (EU) No. 10/2011.
Basic features
| Type: | Conveyors |
|---|---|
| Functionality: | Curve |
| Unit of measure: | Ea |
| Box: | - |
Zero Contact Hygienic
| Internal Radius | Width | Angle | Material | Version | Max working load | Pin material | Fixation | Design | Temperature range dry | Supplementary informations | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | |||||||||||
| P-W02R06G090-CDH | 600 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R06G090-CSH | 600 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | - |
|
| P-W02R06G180-CDH | 600 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R06G180-CSH | 600 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R08G090-CDH | 800 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | - |
|
| P-W02R08G090-CSH | 800 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | - |
|
| P-W02R08G180-CDH | 800 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R08G180-CSH | 800 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R10G090-CDH | 1000 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | - |
|
| P-W02R10G090-CSH | 1000 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R10G180-CDH | 1000 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R10G180-CSH | 1000 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R12G090-CDH | 1200 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | - |
|
| P-W02R12G090-CSH | 1200 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R12G180-CDH | 1200 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R12G180-CSH | 1200 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R14G090-CDH | 1400 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | - |
|
| P-W02R14G090-CSH | 1400 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R14G180-CDH | 1400 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R14G180-CSH | 1400 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R16G090-CDH | 1600 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | - |
|
| P-W02R16G090-CSH | 1600 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R16G180-CDH | 1600 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R16G180-CSH | 1600 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R18G090-CDH | 1800 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | - |
|
| P-W02R18G090-CSH | 1800 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R18G180-CDH | 1800 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R18G180-CSH | 1800 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R20G090-CDH | 2000 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | - |
|
| P-W02R20G090-CSH | 2000 mm | 200 mm (7,87") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R20G180-CDH | 2000 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W02R20G180-CSH | 2000 mm | 200 mm (7,87") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R06G090-CDH | 600 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R06G090-CSH | 600 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R06G180-CDH | 600 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R06G180-CSH | 600 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R08G090-CDH | 800 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R08G090-CSH | 800 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R08G180-CDH | 800 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R08G180-CSH | 800 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R10G090-CDH | 1000 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R10G090-CSH | 1000 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R10G180-CDH | 1000 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R10G180-CSH | 1000 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R12G090-CDH | 1200 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R12G090-CSH | 1200 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R12G180-CDH | 1200 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R12G180-CSH | 1200 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R14G090-CDH | 1400 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R14G090-CSH | 1400 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R14G180-CDH | 1400 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R14G180-CSH | 1400 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R16G090-CDH | 1600 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R16G090-CSH | 1600 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R16G180-CDH | 1600 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R16G180-CSH | 1600 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R18G090-CDH | 1800 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R18G090-CSH | 1800 mm | 400 mm (15,75") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R18G180-CDH | 1800 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W04R18G180-CSH | 1800 mm | 400 mm (15,75") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R06G090-CDH | 600 mm | 600 mm (23,62") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R06G090-CSH | 600 mm | 600 mm (23,62") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R06G180-CDH | 600 mm | 600 mm (23,62") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R06G180-CSH | 600 mm | 600 mm (23,62") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R08G090-CDH | 800 mm | 600 mm (23,62") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R08G090-CSH | 800 mm | 600 mm (23,62") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R08G180-CDH | 800 mm | 600 mm (23,62") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R08G180-CSH | 800 mm | 600 mm (23,62") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R10G090-CDH | 1000 mm | 600 mm (23,62") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R10G090-CSH | 1000 mm | 600 mm (23,62") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R10G180-CDH | 1000 mm | 600 mm (23,62") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R10G180-CSH | 1000 mm | 600 mm (23,62") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R12G090-CDH | 1200 mm | 600 mm (23,62") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R12G090-CSH | 1200 mm | 600 mm (23,62") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R12G180-CDH | 1200 mm | 600 mm (23,62") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R12G180-CSH | 1200 mm | 600 mm (23,62") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R14G090-CDH | 1400 mm | 600 mm (23,62") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R14G090-CSH | 1400 mm | 600 mm (23,62") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R14G180-CDH | 1400 mm | 600 mm (23,62") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R14G180-CSH | 1400 mm | 600 mm (23,62") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R16G090-CDH | 1600 mm | 600 mm (23,62") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R16G090-CSH | 1600 mm | 600 mm (23,62") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R16G180-CDH | 1600 mm | 600 mm (23,62") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W06R16G180-CSH | 1600 mm | 600 mm (23,62") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R06G090-CDH | 600 mm | 800 mm (31,50") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R06G090-CSH | 600 mm | 800 mm (31,50") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R06G180-CDH | 600 mm | 800 mm (31,50") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R06G180-CSH | 600 mm | 800 mm (31,50") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R08G090-CDH | 800 mm | 800 mm (31,50") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R08G090-CSH | 800 mm | 800 mm (31,50") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R08G180-CDH | 800 mm | 800 mm (31,50") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R08G180-CSH | 800 mm | 800 mm (31,50") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R10G090-CDH | 1000 mm | 800 mm (31,50") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R10G090-CSH | 1000 mm | 800 mm (31,50") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R10G180-CDH | 1000 mm | 800 mm (31,50") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R10G180-CSH | 1000 mm | 800 mm (31,50") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R12G090-CDH | 1200 mm | 800 mm (31,50") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R12G090-CSH | 1200 mm | 800 mm (31,50") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R12G180-CDH | 1200 mm | 800 mm (31,50") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R12G180-CSH | 1200 mm | 800 mm (31,50") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R14G090-CDH | 1400 mm | 800 mm (31,50") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R14G090-CSH | 1400 mm | 800 mm (31,50") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R14G180-CDH | 1400 mm | 800 mm (31,50") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W08R14G180-CSH | 1400 mm | 800 mm (31,50") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R06G090-CDH | 600 mm | 1000 mm (39,37") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R06G090-CSH | 600 mm | 1000 mm (39,37") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R06G180-CDH | 600 mm | 1000 mm (39,37") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R06G180-CSH | 600 mm | 1000 mm (39,37") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R08G090-CDH | 800 mm | 1000 mm (39,37") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R08G090-CSH | 800 mm | 1000 mm (39,37") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R08G180-CDH | 800 mm | 1000 mm (39,37") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R08G180-CSH | 800 mm | 1000 mm (39,37") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R10G090-CDH | 1000 mm | 1000 mm (39,37") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R10G090-CSH | 1000 mm | 1000 mm (39,37") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R10G180-CDH | 1000 mm | 1000 mm (39,37") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R10G180-CSH | 1000 mm | 1000 mm (39,37") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R12G090-CDH | 1200 mm | 1000 mm (39,37") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R12G090-CSH | 1200 mm | 1000 mm (39,37") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R12G180-CDH | 1200 mm | 1000 mm (39,37") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W10R12G180-CSH | 1200 mm | 1000 mm (39,37") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W12R06G090-CDH | 600 mm | 1200 mm (47,24") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W12R06G090-CSH | 600 mm | 1200 mm (47,24") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W12R06G180-CDH | 600 mm | 1200 mm (47,24") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W12R06G180-CSH | 600 mm | 1200 mm (47,24") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W12R08G090-CDH | 800 mm | 1200 mm (47,24") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W12R08G090-CSH | 800 mm | 1200 mm (47,24") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W12R08G180-CDH | 800 mm | 1200 mm (47,24") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W12R08G180-CSH | 800 mm | 1200 mm (47,24") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W12R10G090-CDH | 1000 mm | 1200 mm (47,24") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W12R10G090-CSH | 1000 mm | 1200 mm (47,24") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W12R10G180-CDH | 1000 mm | 1200 mm (47,24") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W12R10G180-CSH | 1000 mm | 1200 mm (47,24") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W14R06G090-CDH | 600 mm | 1400 mm (55,12") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W14R06G090-CSH | 600 mm | 1400 mm (55,12") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W14R06G180-CDH | 600 mm | 1400 mm (55,12") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W14R06G180-CSH | 600 mm | 1400 mm (55,12") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W14R08G090-CDH | 800 mm | 1400 mm (55,12") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W14R08G090-CSH | 800 mm | 1400 mm (55,12") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W14R08G180-CDH | 800 mm | 1400 mm (55,12") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W14R08G180-CSH | 800 mm | 1400 mm (55,12") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W16R06G090-CDH | 600 mm | 1600 mm (62,99") | 90° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W16R06G090-CSH | 600 mm | 1600 mm (62,99") | 90° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W16R06G180-CDH | 600 mm | 1600 mm (62,99") | 180° | LFB - Low friction acetal (Blue) | Right | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W16R06G180-CSH | 600 mm | 1600 mm (62,99") | 180° | LFB - Low friction acetal (Blue) | Left | 13500 N/m | PBT white | Snap-in Clip | Zero Contact Hygienic - AISI 304 | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: LFB (Blue) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
