882 M Flat Top
Plastic chains
Description
Basic features
| Series: | 821-882-8257 |
|---|---|
| Pitch: | 38.1 mm |
| Thickness: | 4.8 mm |
| Surface Type: | FT - Flat Top |
| Functionality: | Side Flex MAGNETIC |
| Unit of measure: | Meter |
882 M Flat Top
| Width | Material | Part | Back flex radius | Sideflexing radius min | Mass | Pin material | Box | Max working load | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | |||||||||
| P11130107 | K 750 - 190,5 mm | LF - Low friction acetal (01) | P1113 | 50 mm | 610 mm | 2.14 kg/m | Ferritic Stainless Steel | 10 ft - 3,048 m | 3830 N |
|
| P11130108 | K1000 - 254,0 mm | LF - Low friction acetal (01) | P1113 | 50 mm | 610 mm | 2.45 kg/m | Ferritic Stainless Steel | 10 ft - 3,048 m | 3830 N |
|
| P11130109 | K1200 - 304,8 mm | LF - Low friction acetal (01) | P1113 | 50 mm | 610 mm | 2.68 kg/m | Ferritic Stainless Steel | 10 ft - 3,048 m | 3830 N |
|
| P11130307 | K 750 - 190,5 mm | MX - Performance PBT (03) | P1113 | 50 mm | 610 mm | 2.14 kg/m | Ferritic Stainless Steel | 10 ft - 3,048 m | 3050 N |
|
| P11130308 | K1000 - 254,0 mm | MX - Performance PBT (03) | P1113 | 50 mm | 610 mm | 2.45 kg/m | Ferritic Stainless Steel | 10 ft - 3,048 m | 3050 N |
|
| P11130309 | K1200 - 304,8 mm | MX - Performance PBT (03) | P1113 | 50 mm | 610 mm | 2.68 kg/m | Ferritic Stainless Steel | 10 ft - 3,048 m | 3050 N |
|
