882 split molded sprocket
Chain sprockets
Description
Description
Also suitable for 8257
Basic features
| Series: | 882-8257 |
|---|---|
| Pitch: | 38.1 mm |
| Unit of measure: | Ea |
882 split molded sprocket
| Z- | Bore |
Version | Box | Type | Execution | Pitch diameter | Outer diameter | S dimension | Material | Temperature range dry | Temperature range wet | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | ||||||||||||
| P55601 | 12 | ○ 25 mm | Drive | 4 | Split | Molded | 147.2 mm | 149 mm | 78.4 mm | PA - Polyamide reinforced | -20÷120 °C | -20÷120 °C |
|
| P55602 | 12 | ○ 30 mm | Drive | 4 | Split | Molded | 147.2 mm | 149 mm | 78.4 mm | PA - Polyamide reinforced | -20÷120 °C | -20÷120 °C |
|
| P55603 | 12 | ○ 35 mm | Drive | 4 | Split | Molded | 147.2 mm | 149 mm | 78.4 mm | PA - Polyamide reinforced | -20÷120 °C | -20÷120 °C |
|
| P55604 | 12 | ○ 40 mm | Drive | 4 | Split | Molded | 147.2 mm | 149 mm | 78.4 mm | PA - Polyamide reinforced | -20÷120 °C | -20÷120 °C |
|
| P55651 | 12 | ○ 25 mm | Idler | 4 | Split | Molded | 147.2 mm | 149 mm | 78.4 mm | PA - Polyamide reinforced | -20÷120 °C | -20÷120 °C |
|
| P55652 | 12 | ○ 30 mm | Idler | 4 | Split | Molded | 147.2 mm | 149 mm | 78.4 mm | PA - Polyamide reinforced | -20÷120 °C | -20÷120 °C |
|
| P55653 | 12 | ○ 35 mm | Idler | 4 | Split | Molded | 147.2 mm | 149 mm | 78.4 mm | PA - Polyamide reinforced | -20÷120 °C | -20÷120 °C |
|
| P55654 | 12 | ○ 40 mm | Idler | 4 | Split | Molded | 147.2 mm | 149 mm | 78.4 mm | PA - Polyamide reinforced | -20÷120 °C | -20÷120 °C |
|
