820 Vacuum
Plastic chains
Description
Basic features
| Series: | 820-828-831-878-879-880-888 |
|---|---|
| Pitch: | 38.1 mm |
| Thickness: | 4 mm |
| Surface Type: | V - Vacuum |
| Functionality: | Straight |
| Unit of measure: | Meter |
820 Vacuum
| Width | Material | Part | Back flex radius | Mass | Pin material | Box | Max working load | ||
|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | ||||||||
| P11550102 | K 325 - 82,5 mm | LF - Low friction acetal (01) | P1155 | 50 mm | 0.89 kg/m | Stainless steel | 10 ft - 3,048 m | 1625 N |
|
| P11550105 | K 450 - 114,3 mm | LF - Low friction acetal (01) | P1155 | 50 mm | 1 kg/m | Stainless steel | 10 ft - 3,048 m | 1625 N |
|
