7510 Nub Top
Modular Belts
Description
Description
The nominal tensile strength and the nominal width tolerance are valid for a temperature of 23°C (73 °F).
The actual width of the belt typically falls below the nominal value by 0.1% to 0.3%.
*Belts wider than standard are available with 50 mm increments.
For PE belts up to 750 mm (30”) in width, the reduction ranges from -4 mm to -1 mm, and for widths beyond that, from -0.75% to -0.35%.
For POM belts up to 750 mm (30”) in width, the shrinkage ranges from -4 mm to -1 mm, and for those wider, from -0.75% to -0.35%.
For PP belts up to 750 mm (30”) in width, the decrease is between -3 mm and 0 mm, with the reduction for wider belts ranging from -0.4% to 0%.
Non-Standard belt widths are incremented by 16.65 mm (0.66”). The minimum width is 50 mm (2”).
Non-bricklayed belts are available in widths of 50 mm (2”), 100 mm (4”) and 200 mm (8”).
Basic features
| Series: | 7510 |
|---|---|
| Pitch: | 25.4 mm |
| Thickness: | 11 mm |
| Increments: | 50 mm - 1,97" |
| Surface Type: | NT - Nub Top |
| Functionality: | Straight |
| Unit of measure: | Ea |
7510 Nub Top
| Width | Material | Pin material | Version | Part | Back flex radius | Max working load | Mass | Fixation | Temperature range dry | Supplementary informations | Temperature range wet | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | ||||||||||||
| F7510NTLFB0050-PA6 | 50 mm (1,97'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0050-PBT | 50 mm (1,97'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0050-PE | 50 mm (1,97'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0050-PP | 50 mm (1,97'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0100-PA6 | 100 mm (3,94'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0100-PBT | 100 mm (3,94'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0100-PE | 100 mm (3,94'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0100-PP | 100 mm (3,94'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0150-PA6 | 150 mm (5,91'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0150-PBT | 150 mm (5,91'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0150-PE | 150 mm (5,91'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0150-PP | 150 mm (5,91'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0200-PA6 | 200 mm (7,87'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0200-PBT | 200 mm (7,87'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0200-PE | 200 mm (7,87'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0200-PP | 200 mm (7,87'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0250-PA6 | 250 mm (9,84'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0250-PBT | 250 mm (9,84'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0250-PE | 250 mm (9,84'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0250-PP | 250 mm (9,84'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0300-PA6 | 300 mm (11,81'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0300-PBT | 300 mm (11,81'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0300-PE | 300 mm (11,81'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0300-PP | 300 mm (11,81'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0350-PA6 | 350 mm (13,78'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0350-PBT | 350 mm (13,78'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0350-PE | 350 mm (13,78'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0350-PP | 350 mm (13,78'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0400-PA6 | 400 mm (15,75'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0400-PBT | 400 mm (15,75'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0400-PE | 400 mm (15,75'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0400-PP | 400 mm (15,75'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0450-PA6 | 450 mm (17,72'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0450-PBT | 450 mm (17,72'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0450-PE | 450 mm (17,72'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0450-PP | 450 mm (17,72'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0500-PA6 | 500 mm (19,69'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0500-PBT | 500 mm (19,69'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0500-PE | 500 mm (19,69'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0500-PP | 500 mm (19,69'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0550-PA6 | 550 mm (21,65'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0550-PBT | 550 mm (21,65'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0550-PE | 550 mm (21,65'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0550-PP | 550 mm (21,65'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0600-PA6 | 600 mm (23,62'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0600-PBT | 600 mm (23,62'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0600-PE | 600 mm (23,62'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0600-PP | 600 mm (23,62'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0650-PA6 | 650 mm (25,59'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0650-PBT | 650 mm (25,59'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0650-PE | 650 mm (25,59'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0650-PP | 650 mm (25,59'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0700-PA6 | 700 mm (27,56'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0700-PBT | 700 mm (27,56'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0700-PE | 700 mm (27,56'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0700-PP | 700 mm (27,56'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0750-PA6 | 750 mm (29,53'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0750-PBT | 750 mm (29,53'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0750-PE | 750 mm (29,53'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0750-PP | 750 mm (29,53'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0800-PA6 | 800 mm (31,5'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0800-PBT | 800 mm (31,5'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0800-PE | 800 mm (31,5'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0800-PP | 800 mm (31,5'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0850-PA6 | 850 mm (33,46'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0850-PBT | 850 mm (33,46'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0850-PE | 850 mm (33,46'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0850-PP | 850 mm (33,46'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0900-PA6 | 900 mm (35,43'') | LFB - Low friction acetal (Blue) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0900-PBT | 900 mm (35,43'') | LFB - Low friction acetal (Blue) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0900-PE | 900 mm (35,43'') | LFB - Low friction acetal (Blue) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFB0900-PP | 900 mm (35,43'') | LFB - Low friction acetal (Blue) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0050-PA6 | 50 mm (1,97'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0050-PBT | 50 mm (1,97'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0050-PE | 50 mm (1,97'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0050-PP | 50 mm (1,97'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0100-PA6 | 100 mm (3,94'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0100-PBT | 100 mm (3,94'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0100-PE | 100 mm (3,94'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0100-PP | 100 mm (3,94'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0150-PA6 | 150 mm (5,91'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0150-PBT | 150 mm (5,91'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0150-PE | 150 mm (5,91'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0150-PP | 150 mm (5,91'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0200-PA6 | 200 mm (7,87'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0200-PBT | 200 mm (7,87'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0200-PE | 200 mm (7,87'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0200-PP | 200 mm (7,87'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0250-PA6 | 250 mm (9,84'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0250-PBT | 250 mm (9,84'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0250-PE | 250 mm (9,84'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0250-PP | 250 mm (9,84'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0300-PA6 | 300 mm (11,81'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0300-PBT | 300 mm (11,81'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0300-PE | 300 mm (11,81'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0300-PP | 300 mm (11,81'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0350-PA6 | 350 mm (13,78'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0350-PBT | 350 mm (13,78'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0350-PE | 350 mm (13,78'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0350-PP | 350 mm (13,78'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0400-PA6 | 400 mm (15,75'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0400-PBT | 400 mm (15,75'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0400-PE | 400 mm (15,75'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0400-PP | 400 mm (15,75'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0450-PA6 | 450 mm (17,72'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0450-PBT | 450 mm (17,72'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0450-PE | 450 mm (17,72'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0450-PP | 450 mm (17,72'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0500-PA6 | 500 mm (19,69'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0500-PBT | 500 mm (19,69'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0500-PE | 500 mm (19,69'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0500-PP | 500 mm (19,69'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0550-PA6 | 550 mm (21,65'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0550-PBT | 550 mm (21,65'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0550-PE | 550 mm (21,65'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0550-PP | 550 mm (21,65'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0600-PA6 | 600 mm (23,62'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0600-PBT | 600 mm (23,62'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0600-PE | 600 mm (23,62'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0600-PP | 600 mm (23,62'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0650-PA6 | 650 mm (25,59'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0650-PBT | 650 mm (25,59'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0650-PE | 650 mm (25,59'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0650-PP | 650 mm (25,59'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0700-PA6 | 700 mm (27,56'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0700-PBT | 700 mm (27,56'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0700-PE | 700 mm (27,56'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0700-PP | 700 mm (27,56'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0750-PA6 | 750 mm (29,53'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0750-PBT | 750 mm (29,53'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0750-PE | 750 mm (29,53'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0750-PP | 750 mm (29,53'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0800-PA6 | 800 mm (31,5'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0800-PBT | 800 mm (31,5'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0800-PE | 800 mm (31,5'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0800-PP | 800 mm (31,5'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0850-PA6 | 850 mm (33,46'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0850-PBT | 850 mm (33,46'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0850-PE | 850 mm (33,46'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0850-PP | 850 mm (33,46'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0900-PA6 | 900 mm (35,43'') | LFC - Low friction acetal (cyan) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0900-PBT | 900 mm (35,43'') | LFC - Low friction acetal (cyan) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0900-PE | 900 mm (35,43'') | LFC - Low friction acetal (cyan) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFC0900-PP | 900 mm (35,43'') | LFC - Low friction acetal (cyan) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0050-PA6 | 50 mm (1,97'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0050-PBT | 50 mm (1,97'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0050-PE | 50 mm (1,97'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0050-PP | 50 mm (1,97'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0100-PA6 | 100 mm (3,94'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0100-PBT | 100 mm (3,94'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0100-PE | 100 mm (3,94'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0100-PP | 100 mm (3,94'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0150-PA6 | 150 mm (5,91'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0150-PBT | 150 mm (5,91'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0150-PE | 150 mm (5,91'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0150-PP | 150 mm (5,91'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0200-PA6 | 200 mm (7,87'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0200-PBT | 200 mm (7,87'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0200-PE | 200 mm (7,87'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0200-PP | 200 mm (7,87'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0250-PA6 | 250 mm (9,84'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0250-PBT | 250 mm (9,84'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0250-PE | 250 mm (9,84'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0250-PP | 250 mm (9,84'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0300-PA6 | 300 mm (11,81'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0300-PBT | 300 mm (11,81'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0300-PE | 300 mm (11,81'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0300-PP | 300 mm (11,81'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0350-PA6 | 350 mm (13,78'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0350-PBT | 350 mm (13,78'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0350-PE | 350 mm (13,78'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0350-PP | 350 mm (13,78'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0400-PA6 | 400 mm (15,75'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0400-PBT | 400 mm (15,75'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0400-PE | 400 mm (15,75'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0400-PP | 400 mm (15,75'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0450-PA6 | 450 mm (17,72'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0450-PBT | 450 mm (17,72'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0450-PE | 450 mm (17,72'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0450-PP | 450 mm (17,72'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0500-PA6 | 500 mm (19,69'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0500-PBT | 500 mm (19,69'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0500-PE | 500 mm (19,69'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0500-PP | 500 mm (19,69'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0550-PA6 | 550 mm (21,65'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0550-PBT | 550 mm (21,65'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0550-PE | 550 mm (21,65'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0550-PP | 550 mm (21,65'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0600-PA6 | 600 mm (23,62'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0600-PBT | 600 mm (23,62'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0600-PE | 600 mm (23,62'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0600-PP | 600 mm (23,62'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0650-PA6 | 650 mm (25,59'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0650-PBT | 650 mm (25,59'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0650-PE | 650 mm (25,59'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0650-PP | 650 mm (25,59'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0700-PA6 | 700 mm (27,56'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0700-PBT | 700 mm (27,56'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0700-PE | 700 mm (27,56'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0700-PP | 700 mm (27,56'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0750-PA6 | 750 mm (29,53'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0750-PBT | 750 mm (29,53'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0750-PE | 750 mm (29,53'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0750-PP | 750 mm (29,53'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0800-PA6 | 800 mm (31,5'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0800-PBT | 800 mm (31,5'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0800-PE | 800 mm (31,5'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0800-PP | 800 mm (31,5'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0850-PA6 | 850 mm (33,46'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0850-PBT | 850 mm (33,46'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0850-PE | 850 mm (33,46'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0850-PP | 850 mm (33,46'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0900-PA6 | 900 mm (35,43'') | LFW - Low Friction acetal (White) | PA6 White | No positioners | F7510 | 45 mm | 21900 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0900-PBT | 900 mm (35,43'') | LFW - Low Friction acetal (White) | PBT White | No positioners | F7510 | 45 mm | 42000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0900-PE | 900 mm (35,43'') | LFW - Low Friction acetal (White) | PE White | No positioners | F7510 | 45 mm | 15000 N/m | 7.9 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTLFW0900-PP | 900 mm (35,43'') | LFW - Low Friction acetal (White) | PP White | No positioners | F7510 | 45 mm | 16000 N/m | 7.9 kg/m^2 | Self-Locking Pin | 5÷93 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | -40÷65 °C |
|
| F7510NTPEB0050-PA6 | 50 mm (1,97'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0050-PBT | 50 mm (1,97'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0050-PE | 50 mm (1,97'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0050-PP | 50 mm (1,97'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0100-PA6 | 100 mm (3,94'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0100-PBT | 100 mm (3,94'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | - | - |
|
| F7510NTPEB0100-PE | 100 mm (3,94'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0100-PP | 100 mm (3,94'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0150-PA6 | 150 mm (5,91'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0150-PBT | 150 mm (5,91'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | - | - |
|
| F7510NTPEB0150-PE | 150 mm (5,91'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0150-PP | 150 mm (5,91'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0200-PA6 | 200 mm (7,87'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0200-PBT | 200 mm (7,87'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0200-PE | 200 mm (7,87'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0200-PP | 200 mm (7,87'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0250-PA6 | 250 mm (9,84'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0250-PBT | 250 mm (9,84'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0250-PE | 250 mm (9,84'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0250-PP | 250 mm (9,84'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0300-PA6 | 300 mm (11,81'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0300-PBT | 300 mm (11,81'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0300-PE | 300 mm (11,81'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0300-PP | 300 mm (11,81'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0350-PA6 | 350 mm (13,78'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0350-PBT | 350 mm (13,78'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0350-PE | 350 mm (13,78'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0350-PP | 350 mm (13,78'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0400-PA6 | 400 mm (15,75'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0400-PBT | 400 mm (15,75'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0400-PE | 400 mm (15,75'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0400-PP | 400 mm (15,75'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0450-PA6 | 450 mm (17,72'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0450-PBT | 450 mm (17,72'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0450-PE | 450 mm (17,72'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0450-PP | 450 mm (17,72'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0500-PA6 | 500 mm (19,69'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0500-PBT | 500 mm (19,69'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0500-PE | 500 mm (19,69'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0500-PP | 500 mm (19,69'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0550-PA6 | 550 mm (21,65'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0550-PBT | 550 mm (21,65'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0550-PE | 550 mm (21,65'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0550-PP | 550 mm (21,65'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0600-PA6 | 600 mm (23,62'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0600-PBT | 600 mm (23,62'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0600-PE | 600 mm (23,62'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0600-PP | 600 mm (23,62'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0650-PA6 | 650 mm (25,59'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0650-PBT | 650 mm (25,59'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0650-PE | 650 mm (25,59'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0650-PP | 650 mm (25,59'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0700-PA6 | 700 mm (27,56'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0700-PBT | 700 mm (27,56'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0700-PE | 700 mm (27,56'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0700-PP | 700 mm (27,56'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0750-PA6 | 750 mm (29,53'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0750-PBT | 750 mm (29,53'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0750-PE | 750 mm (29,53'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0750-PP | 750 mm (29,53'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0800-PA6 | 800 mm (31,5'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0800-PBT | 800 mm (31,5'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0800-PE | 800 mm (31,5'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0800-PP | 800 mm (31,5'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0850-PA6 | 850 mm (33,46'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0850-PBT | 850 mm (33,46'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0850-PE | 850 mm (33,46'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0850-PP | 850 mm (33,46'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0900-PA6 | 900 mm (35,43'') | PEB - Polyethylene (blue) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0900-PBT | 900 mm (35,43'') | PEB - Polyethylene (blue) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0900-PE | 900 mm (35,43'') | PEB - Polyethylene (blue) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEB0900-PP | 900 mm (35,43'') | PEB - Polyethylene (blue) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0050-PA6 | 50 mm (1,97'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0050-PBT | 50 mm (1,97'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0050-PE | 50 mm (1,97'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0050-PP | 50 mm (1,97'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0100-PA6 | 100 mm (3,94'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0100-PBT | 100 mm (3,94'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0100-PE | 100 mm (3,94'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0100-PP | 100 mm (3,94'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0150-PA6 | 150 mm (5,91'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0150-PBT | 150 mm (5,91'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0150-PE | 150 mm (5,91'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0150-PP | 150 mm (5,91'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0200-PA6 | 200 mm (7,87'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0200-PBT | 200 mm (7,87'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0200-PE | 200 mm (7,87'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0200-PP | 200 mm (7,87'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0250-PA6 | 250 mm (9,84'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0250-PBT | 250 mm (9,84'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0250-PE | 250 mm (9,84'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0250-PP | 250 mm (9,84'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0300-PA6 | 300 mm (11,81'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0300-PBT | 300 mm (11,81'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0300-PE | 300 mm (11,81'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0300-PP | 300 mm (11,81'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0350-PA6 | 350 mm (13,78'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0350-PBT | 350 mm (13,78'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0350-PE | 350 mm (13,78'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0350-PP | 350 mm (13,78'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0400-PA6 | 400 mm (15,75'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0400-PBT | 400 mm (15,75'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0400-PE | 400 mm (15,75'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0400-PP | 400 mm (15,75'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0450-PA6 | 450 mm (17,72'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0450-PBT | 450 mm (17,72'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0450-PE | 450 mm (17,72'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0450-PP | 450 mm (17,72'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0500-PA6 | 500 mm (19,69'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0500-PBT | 500 mm (19,69'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0500-PE | 500 mm (19,69'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0500-PP | 500 mm (19,69'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0550-PA6 | 550 mm (21,65'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0550-PBT | 550 mm (21,65'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0550-PE | 550 mm (21,65'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0550-PP | 550 mm (21,65'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0600-PA6 | 600 mm (23,62'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0600-PBT | 600 mm (23,62'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0600-PE | 600 mm (23,62'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0600-PP | 600 mm (23,62'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0650-PA6 | 650 mm (25,59'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0650-PBT | 650 mm (25,59'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0650-PE | 650 mm (25,59'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0650-PP | 650 mm (25,59'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0700-PA6 | 700 mm (27,56'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0700-PBT | 700 mm (27,56'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0700-PE | 700 mm (27,56'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0700-PP | 700 mm (27,56'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0750-PA6 | 750 mm (29,53'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0750-PBT | 750 mm (29,53'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0750-PE | 750 mm (29,53'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0750-PP | 750 mm (29,53'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0800-PA6 | 800 mm (31,5'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0800-PBT | 800 mm (31,5'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0800-PE | 800 mm (31,5'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0800-PP | 800 mm (31,5'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0850-PA6 | 850 mm (33,46'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0850-PBT | 850 mm (33,46'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0850-PE | 850 mm (33,46'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0850-PP | 850 mm (33,46'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0900-PA6 | 900 mm (35,43'') | PEC - Polyethylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0900-PBT | 900 mm (35,43'') | PEC - Polyethylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0900-PE | 900 mm (35,43'') | PEC - Polyethylene (cyan) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEC0900-PP | 900 mm (35,43'') | PEC - Polyethylene (cyan) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0050-PA6 | 50 mm (1,97'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0050-PBT | 50 mm (1,97'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0050-PE | 50 mm (1,97'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0050-PP | 50 mm (1,97'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0100-PA6 | 100 mm (3,94'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0100-PBT | 100 mm (3,94'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0100-PE | 100 mm (3,94'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0100-PP | 100 mm (3,94'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0150-PA6 | 150 mm (5,91'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0150-PBT | 150 mm (5,91'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0150-PE | 150 mm (5,91'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0150-PP | 150 mm (5,91'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0200-PA6 | 200 mm (7,87'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0200-PBT | 200 mm (7,87'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0200-PE | 200 mm (7,87'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0200-PP | 200 mm (7,87'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0250-PA6 | 250 mm (9,84'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0250-PBT | 250 mm (9,84'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0250-PE | 250 mm (9,84'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0250-PP | 250 mm (9,84'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0300-PA6 | 300 mm (11,81'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0300-PBT | 300 mm (11,81'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0300-PE | 300 mm (11,81'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0300-PP | 300 mm (11,81'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0350-PA6 | 350 mm (13,78'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0350-PBT | 350 mm (13,78'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0350-PE | 350 mm (13,78'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0350-PP | 350 mm (13,78'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0400-PA6 | 400 mm (15,75'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0400-PBT | 400 mm (15,75'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0400-PE | 400 mm (15,75'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0400-PP | 400 mm (15,75'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0450-PA6 | 450 mm (17,72'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0450-PBT | 450 mm (17,72'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0450-PE | 450 mm (17,72'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0450-PP | 450 mm (17,72'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0500-PA6 | 500 mm (19,69'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0500-PBT | 500 mm (19,69'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0500-PE | 500 mm (19,69'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0500-PP | 500 mm (19,69'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0550-PA6 | 550 mm (21,65'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0550-PBT | 550 mm (21,65'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0550-PE | 550 mm (21,65'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0550-PP | 550 mm (21,65'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0600-PA6 | 600 mm (23,62'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0600-PBT | 600 mm (23,62'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0600-PE | 600 mm (23,62'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0600-PP | 600 mm (23,62'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0650-PA6 | 650 mm (25,59'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0650-PBT | 650 mm (25,59'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0650-PE | 650 mm (25,59'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0650-PP | 650 mm (25,59'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0700-PA6 | 700 mm (27,56'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0700-PBT | 700 mm (27,56'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0700-PE | 700 mm (27,56'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0700-PP | 700 mm (27,56'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0750-PA6 | 750 mm (29,53'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0750-PBT | 750 mm (29,53'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0750-PE | 750 mm (29,53'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0750-PP | 750 mm (29,53'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0800-PA6 | 800 mm (31,5'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0800-PBT | 800 mm (31,5'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0800-PE | 800 mm (31,5'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0800-PP | 800 mm (31,5'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0850-PA6 | 850 mm (33,46'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0850-PBT | 850 mm (33,46'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0850-PE | 850 mm (33,46'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0850-PP | 850 mm (33,46'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0900-PA6 | 900 mm (35,43'') | PEN - Polyethylene (natural) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0900-PBT | 900 mm (35,43'') | PEN - Polyethylene (natural) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0900-PE | 900 mm (35,43'') | PEN - Polyethylene (natural) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEN0900-PP | 900 mm (35,43'') | PEN - Polyethylene (natural) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0050-PA6 | 50 mm (1,97'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0050-PBT | 50 mm (1,97'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0050-PE | 50 mm (1,97'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0050-PP | 50 mm (1,97'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0100-PA6 | 100 mm (3,94'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0100-PBT | 100 mm (3,94'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0100-PE | 100 mm (3,94'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0100-PP | 100 mm (3,94'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0150-PA6 | 150 mm (5,91'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0150-PBT | 150 mm (5,91'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0150-PE | 150 mm (5,91'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0150-PP | 150 mm (5,91'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0200-PA6 | 200 mm (7,87'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0200-PBT | 200 mm (7,87'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0200-PE | 200 mm (7,87'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0200-PP | 200 mm (7,87'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0250-PA6 | 250 mm (9,84'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0250-PBT | 250 mm (9,84'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0250-PE | 250 mm (9,84'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0250-PP | 250 mm (9,84'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0300-PA6 | 300 mm (11,81'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0300-PBT | 300 mm (11,81'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0300-PE | 300 mm (11,81'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0300-PP | 300 mm (11,81'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0350-PA6 | 350 mm (13,78'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0350-PBT | 350 mm (13,78'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0350-PE | 350 mm (13,78'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0350-PP | 350 mm (13,78'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0400-PA6 | 400 mm (15,75'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0400-PBT | 400 mm (15,75'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0400-PE | 400 mm (15,75'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0400-PP | 400 mm (15,75'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0450-PA6 | 450 mm (17,72'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0450-PBT | 450 mm (17,72'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0450-PE | 450 mm (17,72'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0450-PP | 450 mm (17,72'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0500-PA6 | 500 mm (19,69'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0500-PBT | 500 mm (19,69'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0500-PE | 500 mm (19,69'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0500-PP | 500 mm (19,69'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0550-PA6 | 550 mm (21,65'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0550-PBT | 550 mm (21,65'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0550-PE | 550 mm (21,65'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0550-PP | 550 mm (21,65'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0600-PA6 | 600 mm (23,62'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0600-PBT | 600 mm (23,62'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0600-PE | 600 mm (23,62'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0600-PP | 600 mm (23,62'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0650-PA6 | 650 mm (25,59'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0650-PBT | 650 mm (25,59'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0650-PE | 650 mm (25,59'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0650-PP | 650 mm (25,59'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0700-PA6 | 700 mm (27,56'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0700-PBT | 700 mm (27,56'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0700-PE | 700 mm (27,56'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0700-PP | 700 mm (27,56'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0750-PA6 | 750 mm (29,53'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0750-PBT | 750 mm (29,53'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0750-PE | 750 mm (29,53'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0750-PP | 750 mm (29,53'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0800-PA6 | 800 mm (31,5'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0800-PBT | 800 mm (31,5'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0800-PE | 800 mm (31,5'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0800-PP | 800 mm (31,5'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0850-PA6 | 850 mm (33,46'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0850-PBT | 850 mm (33,46'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0850-PE | 850 mm (33,46'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0850-PP | 850 mm (33,46'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0900-PA6 | 900 mm (35,43'') | PEW - Polyethylene (white) | PA6 White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0900-PBT | 900 mm (35,43'') | PEW - Polyethylene (white) | PBT White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -40÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0900-PE | 900 mm (35,43'') | PEW - Polyethylene (white) | PE White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | -70÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPEW0900-PP | 900 mm (35,43'') | PEW - Polyethylene (white) | PP White | No positioners | F7510 | 45 mm | 8000 N/m | 5.7 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | - |
|
| F7510NTPPB0050-PA6 | 50 mm (1,97'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0050-PBT | 50 mm (1,97'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0050-PE | 50 mm (1,97'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0050-PP | 50 mm (1,97'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0100-PA6 | 100 mm (3,94'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0100-PBT | 100 mm (3,94'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0100-PE | 100 mm (3,94'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0100-PP | 100 mm (3,94'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0150-PA6 | 150 mm (5,91'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0150-PBT | 150 mm (5,91'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0150-PE | 150 mm (5,91'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0150-PP | 150 mm (5,91'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0200-PA6 | 200 mm (7,87'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0200-PBT | 200 mm (7,87'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0200-PE | 200 mm (7,87'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0200-PP | 200 mm (7,87'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0250-PA6 | 250 mm (9,84'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0250-PBT | 250 mm (9,84'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0250-PE | 250 mm (9,84'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0250-PP | 250 mm (9,84'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0300-PA6 | 300 mm (11,81'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0300-PBT | 300 mm (11,81'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0300-PE | 300 mm (11,81'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0300-PP | 300 mm (11,81'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0350-PA6 | 350 mm (13,78'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0350-PBT | 350 mm (13,78'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0350-PE | 350 mm (13,78'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0350-PP | 350 mm (13,78'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0400-PA6 | 400 mm (15,75'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0400-PBT | 400 mm (15,75'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0400-PE | 400 mm (15,75'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0400-PP | 400 mm (15,75'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0450-PA6 | 450 mm (17,72'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0450-PBT | 450 mm (17,72'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0450-PE | 450 mm (17,72'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0450-PP | 450 mm (17,72'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0500-PA6 | 500 mm (19,69'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0500-PBT | 500 mm (19,69'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0500-PE | 500 mm (19,69'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0500-PP | 500 mm (19,69'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0550-PA6 | 550 mm (21,65'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0550-PBT | 550 mm (21,65'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0550-PE | 550 mm (21,65'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0550-PP | 550 mm (21,65'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0600-PA6 | 600 mm (23,62'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0600-PBT | 600 mm (23,62'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0600-PE | 600 mm (23,62'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0600-PP | 600 mm (23,62'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0650-PA6 | 650 mm (25,59'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0650-PBT | 650 mm (25,59'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0650-PE | 650 mm (25,59'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0650-PP | 650 mm (25,59'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0700-PA6 | 700 mm (27,56'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0700-PBT | 700 mm (27,56'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0700-PE | 700 mm (27,56'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0700-PP | 700 mm (27,56'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0750-PA6 | 750 mm (29,53'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0750-PBT | 750 mm (29,53'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0750-PE | 750 mm (29,53'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0750-PP | 750 mm (29,53'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0800-PA6 | 800 mm (31,5'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0800-PBT | 800 mm (31,5'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0800-PE | 800 mm (31,5'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0800-PP | 800 mm (31,5'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0850-PA6 | 850 mm (33,46'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0850-PBT | 850 mm (33,46'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0850-PE | 850 mm (33,46'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0850-PP | 850 mm (33,46'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0900-PA6 | 900 mm (35,43'') | PPB - Polypropylene (Blue) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPB0900-PBT | 900 mm (35,43'') | PPB - Polypropylene (Blue) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPB0900-PE | 900 mm (35,43'') | PPB - Polypropylene (Blue) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPB0900-PP | 900 mm (35,43'') | PPB - Polypropylene (Blue) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0050-PA6 | 50 mm (1,97'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0050-PBT | 50 mm (1,97'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0050-PE | 50 mm (1,97'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0050-PP | 50 mm (1,97'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0100-PA6 | 100 mm (3,94'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0100-PBT | 100 mm (3,94'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0100-PE | 100 mm (3,94'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0100-PP | 100 mm (3,94'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0150-PA6 | 150 mm (5,91'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0150-PBT | 150 mm (5,91'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0150-PE | 150 mm (5,91'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0150-PP | 150 mm (5,91'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0200-PA6 | 200 mm (7,87'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0200-PBT | 200 mm (7,87'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0200-PE | 200 mm (7,87'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0200-PP | 200 mm (7,87'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0250-PA6 | 250 mm (9,84'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0250-PBT | 250 mm (9,84'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0250-PE | 250 mm (9,84'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0250-PP | 250 mm (9,84'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0300-PA6 | 300 mm (11,81'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0300-PBT | 300 mm (11,81'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0300-PE | 300 mm (11,81'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0300-PP | 300 mm (11,81'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0350-PA6 | 350 mm (13,78'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0350-PBT | 350 mm (13,78'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0350-PE | 350 mm (13,78'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0350-PP | 350 mm (13,78'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0400-PA6 | 400 mm (15,75'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0400-PBT | 400 mm (15,75'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0400-PE | 400 mm (15,75'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0400-PP | 400 mm (15,75'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0450-PA6 | 450 mm (17,72'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0450-PBT | 450 mm (17,72'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0450-PE | 450 mm (17,72'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0450-PP | 450 mm (17,72'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0500-PA6 | 500 mm (19,69'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0500-PBT | 500 mm (19,69'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0500-PE | 500 mm (19,69'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0500-PP | 500 mm (19,69'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0550-PA6 | 550 mm (21,65'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0550-PBT | 550 mm (21,65'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0550-PE | 550 mm (21,65'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0550-PP | 550 mm (21,65'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0600-PA6 | 600 mm (23,62'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0600-PBT | 600 mm (23,62'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0600-PE | 600 mm (23,62'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0600-PP | 600 mm (23,62'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0650-PA6 | 650 mm (25,59'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0650-PBT | 650 mm (25,59'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0650-PE | 650 mm (25,59'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0650-PP | 650 mm (25,59'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0700-PA6 | 700 mm (27,56'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0700-PBT | 700 mm (27,56'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0700-PE | 700 mm (27,56'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0700-PP | 700 mm (27,56'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0750-PA6 | 750 mm (29,53'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0750-PBT | 750 mm (29,53'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0750-PE | 750 mm (29,53'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0750-PP | 750 mm (29,53'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0800-PA6 | 800 mm (31,5'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0800-PBT | 800 mm (31,5'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0800-PE | 800 mm (31,5'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0800-PP | 800 mm (31,5'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0850-PA6 | 850 mm (33,46'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0850-PBT | 850 mm (33,46'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0850-PE | 850 mm (33,46'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0850-PP | 850 mm (33,46'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0900-PA6 | 900 mm (35,43'') | PPC - Polypropylene (cyan) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPC0900-PBT | 900 mm (35,43'') | PPC - Polypropylene (cyan) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPC0900-PE | 900 mm (35,43'') | PPC - Polypropylene (cyan) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPC0900-PP | 900 mm (35,43'') | PPC - Polypropylene (cyan) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0050-PA6 | 50 mm (1,97'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0050-PBT | 50 mm (1,97'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0050-PE | 50 mm (1,97'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0050-PP | 50 mm (1,97'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0100-PA6 | 100 mm (3,94'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0100-PBT | 100 mm (3,94'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0100-PE | 100 mm (3,94'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0100-PP | 100 mm (3,94'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0150-PA6 | 150 mm (5,91'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0150-PBT | 150 mm (5,91'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0150-PE | 150 mm (5,91'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0150-PP | 150 mm (5,91'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0200-PA6 | 200 mm (7,87'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0200-PBT | 200 mm (7,87'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0200-PE | 200 mm (7,87'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0200-PP | 200 mm (7,87'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0250-PA6 | 250 mm (9,84'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0250-PBT | 250 mm (9,84'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0250-PE | 250 mm (9,84'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0250-PP | 250 mm (9,84'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0300-PA6 | 300 mm (11,81'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0300-PBT | 300 mm (11,81'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0300-PE | 300 mm (11,81'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0300-PP | 300 mm (11,81'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0350-PA6 | 350 mm (13,78'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0350-PBT | 350 mm (13,78'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0350-PE | 350 mm (13,78'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0350-PP | 350 mm (13,78'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0400-PA6 | 400 mm (15,75'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0400-PBT | 400 mm (15,75'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0400-PE | 400 mm (15,75'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0400-PP | 400 mm (15,75'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0450-PA6 | 450 mm (17,72'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0450-PBT | 450 mm (17,72'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0450-PE | 450 mm (17,72'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0450-PP | 450 mm (17,72'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0500-PA6 | 500 mm (19,69'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0500-PBT | 500 mm (19,69'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0500-PE | 500 mm (19,69'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0500-PP | 500 mm (19,69'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0550-PA6 | 550 mm (21,65'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0550-PBT | 550 mm (21,65'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0550-PE | 550 mm (21,65'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0550-PP | 550 mm (21,65'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0600-PA6 | 600 mm (23,62'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0600-PBT | 600 mm (23,62'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0600-PE | 600 mm (23,62'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0600-PP | 600 mm (23,62'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0650-PA6 | 650 mm (25,59'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0650-PBT | 650 mm (25,59'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0650-PE | 650 mm (25,59'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0650-PP | 650 mm (25,59'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0700-PA6 | 700 mm (27,56'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0700-PBT | 700 mm (27,56'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0700-PE | 700 mm (27,56'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0700-PP | 700 mm (27,56'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0750-PA6 | 750 mm (29,53'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0750-PBT | 750 mm (29,53'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0750-PE | 750 mm (29,53'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0750-PP | 750 mm (29,53'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0800-PA6 | 800 mm (31,5'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0800-PBT | 800 mm (31,5'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0800-PE | 800 mm (31,5'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0800-PP | 800 mm (31,5'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0850-PA6 | 850 mm (33,46'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0850-PBT | 850 mm (33,46'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0850-PE | 850 mm (33,46'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0850-PP | 850 mm (33,46'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0900-PA6 | 900 mm (35,43'') | PPW - Polypropylene (white) | PA6 White | No positioners | F7510 | 45 mm | 18600 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷80 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷80 °C |
|
| F7510NTPPW0900-PBT | 900 mm (35,43'') | PPW - Polypropylene (white) | PBT White | No positioners | F7510 | 45 mm | 32000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
| F7510NTPPW0900-PE | 900 mm (35,43'') | PPW - Polypropylene (white) | PE White | No positioners | F7510 | 45 mm | 12000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷65 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷65 °C |
|
| F7510NTPPW0900-PP | 900 mm (35,43'') | PPW - Polypropylene (white) | PP White | No positioners | F7510 | 45 mm | 14000 N/m | 5.5 kg/m^2 | Self-Locking Pin | 0÷100 °C | Self-Cleaning Hinge System Pin diameter: 5 mm Temporary code, to be created specifically on request | 0÷100 °C |
|
Enquiry Now
To allow us to respond to your enquiry promptly, please provide all required information.
Related Products
-
7510 Flat TopModular BeltsView Product -
7510 Diamond TopModular BeltsView Product
-
7510 Mesh TopModular BeltsView Product
-
7520 Flat TopModular BeltsView Product
-
7540 Radius Flush GridModular BeltsView Product
-
7544 Tight Radius Flush GridModular BeltsView Product
-
7510-7520-7540-7544 split machined sprocketBelt sprocketsView Product
-
7510-7520-7540-7544 one-piece molded sprocketBelt sprocketsView Product
