525 Heavy Duty Flat Top + RIB

525 Heavy Duty Flat Top + RIB

	Width	Material	Version	Part	Back flex radius	Max working load	Mass	Pin material	Fixation	Box	Temperature range dry	Temperature range wet	Supplementary informations
Code	All 1020 mm (40,16") 1105 mm (43,50") 1190 mm (46,85") 1275 mm (50,20") 1360 mm (53,54") 1445 mm (56,89") 1530 mm (60,24") 170 mm (6,69") 255 mm (10,04") 340 mm (13,39") 425 mm (16,73") 510 mm (20,08") 595 mm (23,43") 680 mm (26,77") 765 mm (30,12") 85 mm (3,35") 850 mm (33,46") 935 mm (36,81")	All LFA - Low friction acetal (01) MX - Performance PBT (03)	All A - No positioners B - 1 Positioner C - 2 Positioners	All P5261	All 25 mm	All 20500 N/m 25500 N/m	All 8.7 kg/m^2 9 kg/m^2	All PBT white POM grey	All Snap-in Clip	All 4,92 ft - 1,5 m 9,84 ft - 3 m	All -40÷120 °C -40÷80 °C	All -40÷60 °C -40÷65 °C	All - RIB every 5 links Special application in Palletizer	Actions
P5261010085A-XR5	85 mm (3,35")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	9,84 ft - 3 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010085B-XR5	85 mm (3,35")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	9,84 ft - 3 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010085C-XR5	85 mm (3,35")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	9,84 ft - 3 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010170A-XR5	170 mm (6,69")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	9,84 ft - 3 m	-40÷80 °C	-40÷65 °C	-
P5261010170B-XR5	170 mm (6,69")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	9,84 ft - 3 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010170C-XR5	170 mm (6,69")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	9,84 ft - 3 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010255A-XR5	255 mm (10,04")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	9,84 ft - 3 m	-40÷80 °C	-40÷65 °C	-
P5261010255B-XR5	255 mm (10,04")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	9,84 ft - 3 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010255C-XR5	255 mm (10,04")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	9,84 ft - 3 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010340A-XR5	340 mm (13,39")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	-
P5261010340B-XR5	340 mm (13,39")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010340C-XR5	340 mm (13,39")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010425A-XR5	425 mm (16,73")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	-
P5261010425B-XR5	425 mm (16,73")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010425C-XR5	425 mm (16,73")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010510A-XR5	510 mm (20,08")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	-
P5261010510B-XR5	510 mm (20,08")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010510C-XR5	510 mm (20,08")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010595A-XR5	595 mm (23,43")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	-
P5261010595B-XR5	595 mm (23,43")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010595C-XR5	595 mm (23,43")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010680A-XR5	680 mm (26,77")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	-
P5261010680B-XR5	680 mm (26,77")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010680C-XR5	680 mm (26,77")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010765A-XR5	765 mm (30,12")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	-
P5261010765B-XR5	765 mm (30,12")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010765C-XR5	765 mm (30,12")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010850A-XR5	850 mm (33,46")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	-
P5261010850B-XR5	850 mm (33,46")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010850C-XR5	850 mm (33,46")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010935A-XR5	935 mm (36,81")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	-
P5261010935B-XR5	935 mm (36,81")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261010935C-XR5	935 mm (36,81")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011020A-XR5	1020 mm (40,16")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011020B-XR5	1020 mm (40,16")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011020C-XR5	1020 mm (40,16")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011105A-XR5	1105 mm (43,50")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011105B-XR5	1105 mm (43,50")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011105C-XR5	1105 mm (43,50")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011190A-XR5	1190 mm (46,85")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011190B-XR5	1190 mm (46,85")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011190C-XR5	1190 mm (46,85")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011275A-XR5	1275 mm (50,20")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011275B-XR5	1275 mm (50,20")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011275C-XR5	1275 mm (50,20")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011360A-XR5	1360 mm (53,54")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011360B-XR5	1360 mm (53,54")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011360C-XR5	1360 mm (53,54")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011445A-XR5	1445 mm (56,89")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011445B-XR5	1445 mm (56,89")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011445C-XR5	1445 mm (56,89")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011530A-XR5	1530 mm (60,24")	LFA - Low friction acetal (01)	A - No positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011530B-XR5	1530 mm (60,24")	LFA - Low friction acetal (01)	B - 1 Positioner	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261011530C-XR5	1530 mm (60,24")	LFA - Low friction acetal (01)	C - 2 Positioners	P5261	25 mm	25500 N/m	9 kg/m^2	PBT white	Snap-in Clip	4,92 ft - 1,5 m	-40÷80 °C	-40÷65 °C	RIB every 5 links Special application in Palletizer
P5261030085A-XR5	85 mm (3,35")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	9,84 ft - 3 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030085B-XR5	85 mm (3,35")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	9,84 ft - 3 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030085C-XR5	85 mm (3,35")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	9,84 ft - 3 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030170A-XR5	170 mm (6,69")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	9,84 ft - 3 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030170B-XR5	170 mm (6,69")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	9,84 ft - 3 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030170C-XR5	170 mm (6,69")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	9,84 ft - 3 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030255A-XR5	255 mm (10,04")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	9,84 ft - 3 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030255B-XR5	255 mm (10,04")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	9,84 ft - 3 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030255C-XR5	255 mm (10,04")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	9,84 ft - 3 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030340A-XR5	340 mm (13,39")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030340B-XR5	340 mm (13,39")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030340C-XR5	340 mm (13,39")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030425A-XR5	425 mm (16,73")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030425B-XR5	425 mm (16,73")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030425C-XR5	425 mm (16,73")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030510A-XR5	510 mm (20,08")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030510B-XR5	510 mm (20,08")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030510C-XR5	510 mm (20,08")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030595A-XR5	595 mm (23,43")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030595B-XR5	595 mm (23,43")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030595C-XR5	595 mm (23,43")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030680A-XR5	680 mm (26,77")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030680B-XR5	680 mm (26,77")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030680C-XR5	680 mm (26,77")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030765A-XR5	765 mm (30,12")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030765B-XR5	765 mm (30,12")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030765C-XR5	765 mm (30,12")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030850A-XR5	850 mm (33,46")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030850B-XR5	850 mm (33,46")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030850C-XR5	850 mm (33,46")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030935A-XR5	935 mm (36,81")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030935B-XR5	935 mm (36,81")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261030935C-XR5	935 mm (36,81")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031020A-XR5	1020 mm (40,16")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031020B-XR5	1020 mm (40,16")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031020C-XR5	1020 mm (40,16")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031105A-XR5	1105 mm (43,50")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031105B-XR5	1105 mm (43,50")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031105C-XR5	1105 mm (43,50")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031190A-XR5	1190 mm (46,85")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031190B-XR5	1190 mm (46,85")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031190C-XR5	1190 mm (46,85")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031275A-XR5	1275 mm (50,20")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031275B-XR5	1275 mm (50,20")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031275C-XR5	1275 mm (50,20")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031360A-XR5	1360 mm (53,54")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031360B-XR5	1360 mm (53,54")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031360C-XR5	1360 mm (53,54")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031445A-XR5	1445 mm (56,89")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031445B-XR5	1445 mm (56,89")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031445C-XR5	1445 mm (56,89")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031530A-XR5	1530 mm (60,24")	MX - Performance PBT (03)	A - No positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031530B-XR5	1530 mm (60,24")	MX - Performance PBT (03)	B - 1 Positioner	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer
P5261031530C-XR5	1530 mm (60,24")	MX - Performance PBT (03)	C - 2 Positioners	P5261	25 mm	20500 N/m	8.7 kg/m^2	POM grey	Snap-in Clip	4,92 ft - 1,5 m	-40÷120 °C	-40÷60 °C	RIB every 5 links Special application in Palletizer

•
