Zero Contact PRO
Description
Description
The Zero Contact™ PRO is the right choice for heavy duty applications with high abrasive conditions, like sand, salt or sugar as well as production of tiles, bricks and cement production or applications where speeds and loads result very high.
Zero Contact™ PRO is designed with different dimensions and features, so to guarantee higher performance for hostile environments:
Basic features
| Type: | Conveyors |
|---|---|
| Functionality: | Curve |
| Unit of measure: | Ea |
| Box: | - |
Zero Contact PRO
| Internal Radius | Width | Angle | Material | Version | Max working load | Pin material | Fixation | Design | Temperature range dry | Supplementary informations | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | |||||||||||
| P-W91R94G090-CD | 1031 mm | 249 mm (9,80") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W91R94G090-CS | 1031 mm | 249 mm (9,80") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W91R94G180-CD | 1031 mm | 249 mm (9,80") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W91R94G180-CS | 1031 mm | 249 mm (9,80") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W91R97G090-CD | 1286 mm | 249 mm (9,80") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W91R97G090-CS | 1286 mm | 249 mm (9,80") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W91R97G180-CD | 1286 mm | 249 mm (9,80") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W91R97G180-CS | 1286 mm | 249 mm (9,80") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W92R92G090-CD | 756 mm | 269 mm (10,59") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W92R92G090-CS | 756 mm | 269 mm (10,59") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W92R92G180-CD | 756 mm | 269 mm (10,59") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W92R92G180-CS | 756 mm | 269 mm (10,59") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W92R93G090-CD | 1011 mm | 269 mm (10,59") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W92R93G090-CS | 1011 mm | 269 mm (10,59") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W92R93G180-CD | 1011 mm | 269 mm (10,59") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W92R93G180-CS | 1011 mm | 269 mm (10,59") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W93R94G090-CD | 1031 mm | 419 mm (16,50") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W93R94G090-CS | 1031 mm | 419 mm (16,50") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W93R94G180-CD | 1031 mm | 419 mm (16,50") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W93R94G180-CS | 1031 mm | 419 mm (16,50") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W93R96G090-CD | 1201 mm | 419 mm (16,50") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W93R96G090-CS | 1201 mm | 419 mm (16,50") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W93R96G180-CD | 1201 mm | 419 mm (16,50") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W93R96G180-CS | 1201 mm | 419 mm (16,50") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W93R98G090-CD | 1456 mm | 419 mm (16,50") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W93R98G090-CS | 1456 mm | 419 mm (16,50") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | - |
|
| P-W93R98G180-CD | 1456 mm | 419 mm (16,50") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W93R98G180-CS | 1456 mm | 419 mm (16,50") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W94R91G090-CD | 586 mm | 439 mm (17,28") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W94R91G090-CS | 586 mm | 439 mm (17,28") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W94R91G180-CD | 586 mm | 439 mm (17,28") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W94R91G180-CS | 586 mm | 439 mm (17,28") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W94R92G090-CD | 756 mm | 439 mm (17,28") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W94R92G090-CS | 756 mm | 439 mm (17,28") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W94R92G180-CD | 756 mm | 439 mm (17,28") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W94R92G180-CS | 756 mm | 439 mm (17,28") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W94R93G090-CD | 1011 mm | 439 mm (17,28") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W94R93G090-CS | 1011 mm | 439 mm (17,28") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W94R93G180-CD | 1011 mm | 439 mm (17,28") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W94R93G180-CS | 1011 mm | 439 mm (17,28") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W95R95G090-CD | 1116 mm | 504 mm (19,84") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W95R95G090-CS | 1116 mm | 504 mm (19,84") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W95R95G180-CD | 1116 mm | 504 mm (19,84") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W95R95G180-CS | 1116 mm | 504 mm (19,84") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W95R97G090-CD | 1286 mm | 504 mm (19,84") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W95R97G090-CS | 1286 mm | 504 mm (19,84") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W95R97G180-CD | 1286 mm | 504 mm (19,84") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W95R97G180-CS | 1286 mm | 504 mm (19,84") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W95R99G090-CD | 1541 mm | 504 mm (19,84") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W95R99G090-CS | 1541 mm | 504 mm (19,84") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W95R99G180-CD | 1541 mm | 504 mm (19,84") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W95R99G180-CS | 1541 mm | 504 mm (19,84") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W96R91G090-CD | 586 mm | 524 mm (20,63") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W96R91G090-CS | 586 mm | 524 mm (20,63") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W96R91G180-CD | 586 mm | 524 mm (20,63") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W96R91G180-CS | 586 mm | 524 mm (20,63") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W96R92G090-CD | 756 mm | 524 mm (20,63") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W96R92G090-CS | 756 mm | 524 mm (20,63") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W96R92G180-CD | 756 mm | 524 mm (20,63") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W96R92G180-CS | 756 mm | 524 mm (20,63") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W96R93G090-CD | 1011 mm | 524 mm (20,63") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W96R93G090-CS | 1011 mm | 524 mm (20,63") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W96R93G180-CD | 1011 mm | 524 mm (20,63") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W96R93G180-CS | 1011 mm | 524 mm (20,63") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W97R91G090-CD | 586 mm | 864 mm (34,02") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W97R91G090-CS | 586 mm | 864 mm (34,02") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W97R91G180-CD | 586 mm | 864 mm (34,02") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W97R91G180-CS | 586 mm | 864 mm (34,02") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W97R92G090-CD | 756 mm | 864 mm (34,02") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W97R92G090-CS | 756 mm | 864 mm (34,02") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W97R92G180-CD | 756 mm | 864 mm (34,02") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W97R92G180-CS | 756 mm | 864 mm (34,02") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W97R93G090-CD | 1011 mm | 864 mm (34,02") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W97R93G090-CS | 1011 mm | 864 mm (34,02") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W97R93G180-CD | 1011 mm | 864 mm (34,02") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W97R93G180-CS | 1011 mm | 864 mm (34,02") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W98R91G090-CD | 586 mm | 1034 mm (40,71") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W98R91G090-CS | 586 mm | 1034 mm (40,71") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W98R91G180-CD | 586 mm | 1034 mm (40,71") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W98R91G180-CS | 586 mm | 1034 mm (40,71") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W98R92G090-CD | 756 mm | 1034 mm (40,71") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W98R92G090-CS | 756 mm | 1034 mm (40,71") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W98R92G180-CD | 756 mm | 1034 mm (40,71") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W98R92G180-CS | 756 mm | 1034 mm (40,71") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W98R93G090-CD | 1011 mm | 1034 mm (40,71") | 90° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W98R93G090-CS | 1011 mm | 1034 mm (40,71") | 90° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W98R93G180-CD | 1011 mm | 1034 mm (40,71") | 180° | PA - Glass Fiber Reinforced (28) | Right | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
| P-W98R93G180-CS | 1011 mm | 1034 mm (40,71") | 180° | PA - Glass Fiber Reinforced (28) | Left | 19000 N/m | Stainless steel | Grub Screw | Zero Contact PRO | -5÷45 (non condensing) °C | OPEN AREA 0% Color of modules: Dark Pigeon Blue (RAL 5017) These codes mean complete curve, except floor supports and gearmotor, if you need to include them please see the dedicated section. |
|
