Straight track 1843 TAB
Straight track
Description
Description
TAB type corner tracks are a more economical solution compared to magnetic curves.
In those applications where cleaning and product support are less important, they can perfectly be used.
Basic features
| Series: | 1843 TAB |
|---|---|
| Type: | Tab |
| Box: | - |
Straight track 1843 TAB
| Chain/Belt Width | Length | Total Height | Unit of measure | Tracks | Basic width | Total width | Material UP | UP Height | Shoe | Temperature range dry | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | |||||||||||
| P79321010 | K 125 (31,75 mm) | 2000 mm mm | 25 mm | Ea | 1 | 50 mm | 50 mm | UHMW-PE Black | 25 mm | Not included | -40÷80 °C |
|
| P79321010B | K 125 (31,75 mm) | 2000 mm mm | 25 mm | Ea | 1 | 50 mm | 50 mm | BluLub | 25 mm | Not included | -40÷50 °C |
|
| P79321010C | K 125 (31,75 mm) | 2000 mm mm | 25 mm | Ea | 1 | 50 mm | 50 mm | UHMW-PE Abrasive | 25 mm | Not included | -40÷80 °C |
|
| P79322010 | K 200 (50,80 mm) | 2000 mm mm | 25 mm | Ea | 1 | 70 mm | 70 mm | UHMW-PE Black | 25 mm | Not included | -40÷80 °C |
|
| P79322010B | K 200 (50,80 mm) | 2000 mm mm | 25 mm | Ea | 1 | 70 mm | 70 mm | BluLub | 25 mm | Not included | -40÷50 °C |
|
| P79322010C | K 200 (50,80 mm) | 2000 mm mm | 25 mm | Ea | 1 | 70 mm | 70 mm | UHMW-PE Abrasive | 25 mm | Not included | -40÷80 °C |
|
