Replacement curve KIT 882-8857 M

Curve

Enquire Now

Description

The kit replacement procedure can be done with the curve still mounted in the conveyor, this saves time and costs, with easy troubleshooting. Remove the worn guides from the top of the curve; this can be done by inserting a flat screwdriver between the guide and the support base, and with the help of a hammer, leverage all the way round to lift the guide. Install the new guide on the support base. Place the new guide in the appropriate seat, and using a soft hammer hit gently stab its upper surface the guide. Make sure guide is firmly seated in the slot. Now the guides are mounted properly and the conveyor can be reassembled. Don't forget to turn off and lock-out the conveyor power before proceeding with the replacement of the guide, and ensure that the chain ends cannot slip away because of its weight.

Basic features

Series:	882-8857 M
Type:	Magnetic
Box:	-

Replacement curve KIT 882-8857 M

	Chain/Belt Width	Radius	Angle	Unit of measure	Tracks	Basic width	Pitch	Total width	Infeed / Outfeed	Material UP	Material LW	UP Height	Temperature range dry	Supplementary informations
Code															Actions
P80818610RS-KIT	K 750 (190,50 mm)	860 mm	90°	Ea	1	214 mm	- mm	214 mm	0	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80818610RSC-KIT	K 750 (190,50 mm)	860 mm	90°	Ea	1	214 mm	- mm	214 mm	0	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80818610RSH-KIT	K 750 (190,50 mm)	860 mm	90°	Ea	1	214 mm	- mm	214 mm	0	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80818620RS-KIT	K 750 (190,50 mm)	860 mm	90°	Ea	2	214 mm	200 mm	414 mm	0	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80818620RSC-KIT	K 750 (190,50 mm)	860 mm	90°	Ea	2	214 mm	200 mm	414 mm	0	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80818620RSH-KIT	K 750 (190,50 mm)	860 mm	90°	Ea	2	214 mm	200 mm	414 mm	0	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80818630RS-KIT	K 750 (190,50 mm)	860 mm	90°	Ea	3	214 mm	200 mm	614 mm	0	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80818630RSC-KIT	K 750 (190,50 mm)	860 mm	90°	Ea	3	214 mm	200 mm	614 mm	0	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80818630RSH-KIT	K 750 (190,50 mm)	860 mm	90°	Ea	3	214 mm	200 mm	614 mm	0	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80918610RS-KIT	K1000 (254 mm)	860 mm	90°	Ea	1	270 mm	- mm	270 mm	0	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80918610RSC-KIT	K1000 (254 mm)	860 mm	90°	Ea	1	270 mm	- mm	270 mm	0	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80918610RSH-KIT	K1000 (254 mm)	860 mm	90°	Ea	1	270 mm	- mm	270 mm	0	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80919610RS-KIT	K1000 (254 mm)	1000 mm	90°	Ea	1	270 mm	- mm	270 mm	0	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80919610RSC-KIT	K1000 (254 mm)	1000 mm	90°	Ea	1	270 mm	- mm	270 mm	0	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P80919610RSH-KIT	K1000 (254 mm)	1000 mm	90°	Ea	1	270 mm	- mm	270 mm	0	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81018610RS-KIT	K1200 (304,80 mm)	860 mm	90°	Ea	1	320 mm	- mm	320 mm	0	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81018610RSC-KIT	K1200 (304,80 mm)	860 mm	90°	Ea	1	320 mm	- mm	320 mm	0	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81018610RSH-KIT	K1200 (304,80 mm)	860 mm	90°	Ea	1	320 mm	- mm	320 mm	0	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81019610RS-KIT	K1200 (304,80 mm)	1000 mm	90°	Ea	1	320 mm	- mm	320 mm	0	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81019610RSC-KIT	K1200 (304,80 mm)	1000 mm	90°	Ea	1	320 mm	- mm	320 mm	0	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81019610RSH-KIT	K1200 (304,80 mm)	1000 mm	90°	Ea	1	320 mm	- mm	320 mm	0	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81713614RS-KIT	K 750 (190,50 mm)	610 mm	90°	Ea	1	200 mm	- mm	200 mm	100	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81713614RSC-KIT	K 750 (190,50 mm)	610 mm	90°	Ea	1	200 mm	- mm	200 mm	100	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	-
P81713614RSH-KIT	K 750 (190,50 mm)	610 mm	90°	Ea	1	200 mm	- mm	200 mm	100	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	-
P81713624RS-KIT	K 750 (190,50 mm)	610 mm	90°	Ea	2	200 mm	195 mm	395 mm	100	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	-
P81713624RSC-KIT	K 750 (190,50 mm)	610 mm	90°	Ea	2	200 mm	195 mm	395 mm	100	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	-
P81713624RSH-KIT	K 750 (190,50 mm)	610 mm	90°	Ea	2	200 mm	195 mm	395 mm	100	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	-
P81713634RS-KIT	K 750 (190,50 mm)	610 mm	90°	Ea	3	200 mm	195 mm	590 mm	100	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	-
P81713634RSC-KIT	K 750 (190,50 mm)	610 mm	90°	Ea	3	200 mm	195 mm	590 mm	100	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81713634RSH-KIT	K 750 (190,50 mm)	610 mm	90°	Ea	3	200 mm	195 mm	590 mm	100	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	-
P81713644RS-KIT	K 750 (190,50 mm)	610 mm	90°	Ea	4	200 mm	195 mm	785 mm	100	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	-
P81713644RSC-KIT	K 750 (190,50 mm)	610 mm	90°	Ea	4	200 mm	195 mm	785 mm	100	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81713644RSH-KIT	K 750 (190,50 mm)	610 mm	90°	Ea	4	200 mm	195 mm	785 mm	100	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	-
P81816614RS-KIT	K 750 (190,50 mm)	750 mm	90°	Ea	1	200 mm	- mm	200 mm	100	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81816614RSC-KIT	K 750 (190,50 mm)	750 mm	90°	Ea	1	200 mm	- mm	200 mm	100	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81816614RSH-KIT	K 750 (190,50 mm)	750 mm	90°	Ea	1	200 mm	- mm	200 mm	100	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81816624RS-KIT	K 750 (190,50 mm)	750 mm	90°	Ea	2	200 mm	195 mm	395 mm	100	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81816624RSC-KIT	K 750 (190,50 mm)	750 mm	90°	Ea	2	200 mm	195 mm	395 mm	100	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81816624RSH-KIT	K 750 (190,50 mm)	750 mm	90°	Ea	2	200 mm	195 mm	395 mm	100	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81816634RS-KIT	K 750 (190,50 mm)	750 mm	90°	Ea	3	200 mm	195 mm	590 mm	100	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81816634RSC-KIT	K 750 (190,50 mm)	750 mm	90°	Ea	3	200 mm	195 mm	590 mm	100	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81816634RSH-KIT	K 750 (190,50 mm)	750 mm	90°	Ea	3	200 mm	195 mm	590 mm	100	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81919614RS-KIT	K 750 (190,50 mm)	1000 mm	90°	Ea	1	200 mm	- mm	200 mm	100	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81919614RSC-KIT	K 750 (190,50 mm)	1000 mm	90°	Ea	1	200 mm	- mm	200 mm	100	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81919614RSH-KIT	K 750 (190,50 mm)	1000 mm	90°	Ea	1	200 mm	- mm	200 mm	100	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81919624RS-KIT	K 750 (190,50 mm)	1000 mm	90°	Ea	2	200 mm	195 mm	395 mm	100	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81919624RSC-KIT	K 750 (190,50 mm)	1000 mm	90°	Ea	2	200 mm	195 mm	395 mm	100	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81919624RSH-KIT	K 750 (190,50 mm)	1000 mm	90°	Ea	2	200 mm	195 mm	395 mm	100	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81919634RS-KIT	K 750 (190,50 mm)	1000 mm	90°	Ea	3	200 mm	195 mm	590 mm	100	RS - BluLub	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81919634RSC-KIT	K 750 (190,50 mm)	1000 mm	90°	Ea	3	200 mm	195 mm	590 mm	100	RS - UHMW-PE Abrasive	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
P81919634RSH-KIT	K 750 (190,50 mm)	1000 mm	90°	Ea	3	200 mm	195 mm	590 mm	100	RS - UHMW-PE Grey	UHMW-PE Black	32 mm	-40÷50 °C	NEW standard RS design Custom curves available, please see the special form
