Part 372
Knob-handle-hinge
Description
Basic features
| Type: | Hinge |
|---|---|
| Material: | Plastic |
| Unit of measure: | Ea |
| Box: | 6 |
Part 372
| Part | Material | A | B | D | Color | E | C | Temperature range dry | Temperature range wet | Supplementary informations | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | |||||||||||
| P37201 | P372 | Reinforced polyamide | 11 mm | 14 mm | 6,5 mm | Black | 6 mm | 10.5 mm | -20÷120 °C | -20÷120 °C | Pin material: Stainless steel |
|
| P37202 | P372 | Reinforced polyamide | 11 mm | 14 mm | 8,5 mm | Black | 8 mm | 13,5 mm | -20÷120 °C | -20÷120 °C | Pin material: Stainless steel |
|
| P37203 | P372 | Reinforced polyamide | 18 mm | 21 mm | 8,5 mm | Black | 8 mm | 13.5 mm | -20÷120 °C | -20÷120 °C | Pin material: Stainless steel |
|
| P37211 | P372 | Reinforced polyamide | 11 mm | 14 mm | 6,5 mm | Hygienic blue | 6 mm | 10.5 mm | -20÷120 °C | -20÷120 °C | Pin material: Stainless steel |
|
| P37212 | P372 | Reinforced polyamide | 11 mm | 14 mm | 8,5 mm | Hygienic blue | 8 mm | 13.5 mm | -20÷120 °C | -20÷120 °C | Pin material: Stainless steel |
|
| P37213 | P372 | Reinforced polyamide | 18 mm | 21 mm | 8,5 mm | Hygienic blue | 8 mm | 13.5 mm | -20÷120 °C | -20÷120 °C | Pin material: Stainless steel |
|
