Part 311

Brackets

Enquire Now

Description

Basic features

Type:	Bracket
Material:	Plastic
Version:	Adjustable
Unit of measure:	Ea
Box:	12

Part 311

	Part	Material	ØA	B	Color	Knob type	Knob color	Temperature range dry	Temperature range wet
Code										Actions
P31101	P311	Support: Reinforced PA; Knob: Reinforced PA + nickel plated brass; Eyebolt: Stainless steel; Head: Reinforced PA	12	9 mm	Black	Plastic	Black	-20÷120 °C	-20÷120 °C
P31102	P311	Support: Reinforced PA; Knob: Reinforced PA + nickel plated brass; Eyebolt: Stainless steel; Head: Reinforced PA	16	9 mm	Black	Plastic	Black	-20÷120 °C	-20÷120 °C
P31103	P311	Support: Reinforced PA; Knob: Reinforced PA + nickel plated brass; Eyebolt: Stainless steel; Head: Reinforced PA	12	10.5 mm	Black	Plastic	Black	-20÷120 °C	-20÷120 °C
P31104	P311	Support: Reinforced PA; Knob: Reinforced PA + nickel plated brass; Eyebolt: Stainless steel; Head: Reinforced PA	16	10.5 mm	Black	Plastic	Black	-20÷120 °C	-20÷120 °C
P31105	P311	Support: Reinforced PA; Knob: Reinforced PA + nickel plated brass; Eyebolt: Stainless steel; Head: Reinforced PA	14	9 mm	Black	Plastic	Black	-20÷120 °C	-20÷120 °C
P31106	P311	Support: Reinforced PA; Knob: Reinforced PA + nickel plated brass; Eyebolt: Stainless steel; Head: Reinforced PA	14	10.5 mm	Black	Plastic	Black	-20÷120 °C	-20÷120 °C
P31109	P311	Support: Reinforced PA; Knob: Reinforced PA + nickel plated brass; Eyebolt: Stainless steel; Head: Reinforced PA	bracket	9 mm	Black	Plastic	Black	-20÷120 °C	-20÷120 °C
P31110	P311	Support: Reinforced PA; Knob: Reinforced PA + nickel plated brass; Eyebolt: Stainless steel; Head: Reinforced PA	bracket	10.5 mm	Black	Plastic	Black	-20÷120 °C	-20÷120 °C
