Home Fixed and Revolving Handles Fixed handles EBK-C SOFT

EBK-C SOFT

Mushroom lobe handles

'Soft-touch' technopolymer

Enquire Now

Description

Main specifications

Material

High-resilience polypropylene based (PP) technopolymer, coated with 'soft-touch' thermoplastic elastomer (TPE) chemically bonded, hardness 70 Shore A, black colour, matte finish.

Raw material coating suitable for contact with food (FDA CFR.21 and EU 10/2011).

Centre cap

Polypropylene based (PP) technopolymer, in Elecolors colours, matte finish, press-fit assembly.

Standard execution

Brass boss, threaded hole.

General information

Features and applications

The coating, with 'soft-touch' elastomer, improves the grip even in the presence of oils, greases and sweat from the hand. For this reason it is suitable for fitness machines, tools and machines for gardening and goods transport, high-precision instruments and disability aids.

		Color	D	L	d_6H	d₁	h	l₁
Code	Description									Actions
245103-C2	EBK.43 B-M8-C-SOFT-C2	C2 - RAL 2004	43	53.5	M8	32.5	18	17.5	62
245103-C3	EBK.43 B-M8-C-SOFT-C3	C3 - RAL 7035	43	53.5	M8	32.5	18	17.5	62
245103-C4	EBK.43 B-M8-C-SOFT-C4	C4 - RAL 1021	43	53.5	M8	32.5	18	17.5	62
245103-C5	EBK.43 B-M8-C-SOFT-C5	C5 - RAL 5024	43	53.5	M8	32.5	18	17.5	62
245103-C6	EBK.43 B-M8-C-SOFT-C6	C6 - RAL 3000	43	53.5	M8	32.5	18	17.5	62
245103-C17	EBK.43 B-M8-C-SOFT-C17	C17 - RAL 6017	43	53.5	M8	32.5	18	17.5	56
245105-C2	EBK.43 B-M10-C-SOFT-C2	C2 - RAL 2004	43	53.5	M10	32.5	18	17.5	82
245105-C3	EBK.43 B-M10-C-SOFT-C3	C3 - RAL 7035	43	53.5	M10	32.5	18	17.5	82
245105-C4	EBK.43 B-M10-C-SOFT-C4	C4 - RAL 1021	43	53.5	M10	32.5	18	17.5	82
245105-C5	EBK.43 B-M10-C-SOFT-C5	C5 - RAL 5024	43	53.5	M10	32.5	18	17.5	82
245105-C6	EBK.43 B-M10-C-SOFT-C6	C6 - RAL 3000	43	53.5	M10	32.5	18	17.5	82
245105-C17	EBK.43 B-M10-C-SOFT-C17	C17 - RAL 6017	43	53.5	M10	32.5	18	17.5	82
245203-C2	EBK.50 B-M8-C-SOFT-C2	C2 - RAL 2004	50	60	M8	37	20	20	95
245203-C3	EBK.50 B-M8-C-SOFT-C3	C3 - RAL 7035	50	60	M8	37	20	20	95
245203-C4	EBK.50 B-M8-C-SOFT-C4	C4 - RAL 1021	50	60	M8	37	20	20	104
245203-C5	EBK.50 B-M8-C-SOFT-C5	C5 - RAL 5024	50	60	M8	37	20	20	104
245203-C6	EBK.50 B-M8-C-SOFT-C6	C6 - RAL 3000	50	60	M8	37	20	20	95
245203-C17	EBK.50 B-M8-C-SOFT-C17	C17 - RAL 6017	50	60	M8	37	20	20	95
245205-C2	EBK.50 B-M10-C-SOFT-C2	C2 - RAL 2004	50	60	M10	37	20	20	92
245205-C3	EBK.50 B-M10-C-SOFT-C3	C3 - RAL 7035	50	60	M10	37	20	20	92
245205-C4	EBK.50 B-M10-C-SOFT-C4	C4 - RAL 1021	50	60	M10	37	20	20	92
245205-C5	EBK.50 B-M10-C-SOFT-C5	C5 - RAL 5024	50	60	M10	37	20	20	92
245205-C6	EBK.50 B-M10-C-SOFT-C6	C6 - RAL 3000	50	60	M10	37	20	20	92
245205-C17	EBK.50 B-M10-C-SOFT-C17	C17 - RAL 6017	50	60	M10	37	20	20	92
245207-C2	EBK.50 B-M12-C-SOFT-C2	C2 - RAL 2004	50	60	M12	37	20	20	90
245207-C3	EBK.50 B-M12-C-SOFT-C3	C3 - RAL 7035	50	60	M12	37	20	20	90
245207-C4	EBK.50 B-M12-C-SOFT-C4	C4 - RAL 1021	50	60	M12	37	20	20	90
245207-C5	EBK.50 B-M12-C-SOFT-C5	C5 - RAL 5024	50	60	M12	37	20	20	90
245207-C6	EBK.50 B-M12-C-SOFT-C6	C6 - RAL 3000	50	60	M12	37	20	20	90
245207-C17	EBK.50 B-M12-C-SOFT-C17	C17 - RAL 6017	50	60	M12	37	20	20	90
