Curve 600 Standard and Small radius- TAB, REVERSE TAB, TAB REVERSE TAB

Curve
Enquire Now
  • product-image

Description

Description
TAB type corner tracks are a more economical solution compared to magnetic curves. In those applications where cleaning and product support are less important, they can perfectly be used.
Basic features
Series: 600
Type: Tab
Box: -

Curve 600 Standard and Small radius- TAB, REVERSE TAB, TAB REVERSE TAB

Chain/Belt Width Radius Total Height Angle Version Unit of measure Total width Infeed / Outfeed Material UP Material LW UP Height LW Height Shoe Temperature range dry Supplementary informations
Code Actions
P76141114 255 mm 515 mm 80 mm 15° Standard Ea 285 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76141214 255 mm 515 mm 80 mm 30° Standard Ea 285 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C - cart-icon
P76141314 255 mm 515 mm 80 mm 45° Standard Ea 285 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76141414 255 mm 515 mm 80 mm 60° Standard Ea 285 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76141514 255 mm 515 mm 80 mm 75° Standard Ea 285 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76141614 255 mm 515 mm 80 mm 90° Standard Ea 285 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76142124 340 mm 685 mm 80 mm 15° Standard Ea 370 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C - cart-icon
P76142224 340 mm 685 mm 80 mm 30° Standard Ea 370 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C - cart-icon
P76142324 340 mm 685 mm 80 mm 45° Standard Ea 370 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76142424 340 mm 685 mm 80 mm 60° Standard Ea 370 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76142524 340 mm 685 mm 80 mm 75° Standard Ea 370 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76142624 340 mm 685 mm 80 mm 90° Standard Ea 370 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76143134 425 mm 855 mm 80 mm 15° Standard Ea 455 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C - cart-icon
P76143234 425 mm 855 mm 80 mm 30° Standard Ea 455 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76143334 425 mm 855 mm 80 mm 45° Standard Ea 455 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76143434 425 mm 855 mm 80 mm 60° Standard Ea 455 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76143534 425 mm 855 mm 80 mm 75° Standard Ea 455 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76143634 425 mm 855 mm 80 mm 90° Standard Ea 455 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76144144 510 mm 1025 mm 80 mm 15° Standard Ea 540 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C - cart-icon
P76144244 510 mm 1025 mm 80 mm 30° Standard Ea 540 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76144344 510 mm 1025 mm 80 mm 45° Standard Ea 540 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76144444 510 mm 1025 mm 80 mm 60° Standard Ea 540 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76144544 510 mm 1025 mm 80 mm 75° Standard Ea 540 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76144644 510 mm 1025 mm 80 mm 90° Standard Ea 540 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76145154 595 mm 1195 mm 80 mm 15° Standard Ea 625 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C - cart-icon
P76145254 595 mm 1195 mm 80 mm 30° Standard Ea 625 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76145354 595 mm 1195 mm 80 mm 45° Standard Ea 625 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76145454 595 mm 1195 mm 80 mm 60° Standard Ea 625 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76145554 595 mm 1195 mm 80 mm 75° Standard Ea 625 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76145654 595 mm 1195 mm 80 mm 90° Standard Ea 625 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76146164 680 mm 1365 mm 80 mm 15° Standard Ea 710mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C - cart-icon
P76146264 680 mm 1365 mm 80 mm 30° Standard Ea 710mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76146364 680 mm 1365 mm 80 mm 45° Standard Ea 710mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76146464 680 mm 1365 mm 80 mm 60° Standard Ea 710mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76146564 680 mm 1365 mm 80 mm 75° Standard Ea 710mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76146664 680 mm 1365 mm 80 mm 90° Standard Ea 710mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76147174 765 mm 1535 mm 80 mm 15° Standard Ea 795 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C - cart-icon
P76147274 765 mm 1535 mm 80 mm 30° Standard Ea 795 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76147374 765 mm 1535 mm 80 mm 45° Standard Ea 795 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76147474 765 mm 1535 mm 80 mm 60° Standard Ea 795 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76147574 765 mm 1535 mm 80 mm 75° Standard Ea 795 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76147674 765 mm 1535 mm 80 mm 90° Standard Ea 795 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76148184 850 mm 1705 mm 80 mm 15° Standard Ea 880 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C - cart-icon
P76148284 850 mm 1705 mm 80 mm 30° Standard Ea 880 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76148384 850 mm 1705 mm 80 mm 45° Standard Ea 880 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76148484 850 mm 1705 mm 80 mm 60° Standard Ea 880 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76148584 850 mm 1705 mm 80 mm 75° Standard Ea 880 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76148684 850 mm 1705 mm 80 mm 90° Standard Ea 880 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76151124 340 mm 405 mm 80 mm 15° Small radius Ea 370 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76151224 340 mm 405 mm 80 mm 30° Small radius Ea 370 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76151324 340 mm 405 mm 80 mm 45° Small radius Ea 370 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76151424 340 mm 405 mm 80 mm 60° Small radius Ea 370 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76151524 340 mm 405 mm 80 mm 75° Small radius Ea 370 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76151624 340 mm 405 mm 80 mm 90° Small radius Ea 370 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76152134 425 mm 505 mm 80 mm 15° Small radius Ea 455 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76152234 425 mm 505 mm 80 mm 30° Small radius Ea 455 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76152334 425 mm 505 mm 80 mm 45° Small radius Ea 455 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76152434 425 mm 505 mm 80 mm 60° Small radius Ea 455 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76152534 425 mm 505 mm 80 mm 75° Small radius Ea 455 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76152634 425 mm 505 mm 80 mm 90° Small radius Ea 455 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76153144 510 mm 605 mm 80 mm 15° Small radius Ea 540 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76153244 510 mm 605 mm 80 mm 30° Small radius Ea 540 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76153344 510 mm 605 mm 80 mm 45° Small radius Ea 540 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76153444 510 mm 605 mm 80 mm 60° Small radius Ea 540 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76153544 510 mm 605 mm 80 mm 75° Small radius Ea 540 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76153644 510 mm 605 mm 80 mm 90° Small radius Ea 540 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76154154 595 mm 725 mm 80 mm 15° Small radius Ea 625 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76154254 595 mm 725 mm 80 mm 30° Small radius Ea 625 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76154354 595 mm 725 mm 80 mm 45° Small radius Ea 625 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76154454 595 mm 725 mm 80 mm 60° Small radius Ea 625 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76154554 595 mm 725 mm 80 mm 75° Small radius Ea 625 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76154654 595 mm 725 mm 80 mm 90° Small radius Ea 625 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76155164 680 mm 885 mm 80 mm 15° Small radius Ea 710mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76155264 680 mm 885 mm 80 mm 30° Small radius Ea 710mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76155364 680 mm 885 mm 80 mm 45° Small radius Ea 710mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76155464 680 mm 885 mm 80 mm 60° Small radius Ea 710mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76155564 680 mm 885 mm 80 mm 75° Small radius Ea 710mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76155664 680 mm 885 mm 80 mm 90° Small radius Ea 710mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76156174 765 mm 1045 mm 80 mm 15° Small radius Ea 795 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76156274 765 mm 1045 mm 80 mm 30° Small radius Ea 795 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76156374 765 mm 1045 mm 80 mm 45° Small radius Ea 795 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76156474 765 mm 1045 mm 80 mm 60° Small radius Ea 795 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76156574 765 mm 1045 mm 80 mm 75° Small radius Ea 795 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76156674 765 mm 1045 mm 80 mm 90° Small radius Ea 795 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76157184 850 mm 1205 mm 80 mm 15° Small radius Ea 880 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76157284 850 mm 1205 mm 80 mm 30° Small radius Ea 880 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76157384 850 mm 1205 mm 80 mm 45° Small radius Ea 880 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76157484 850 mm 1205 mm 80 mm 60° Small radius Ea 880 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76157584 850 mm 1205 mm 80 mm 75° Small radius Ea 880 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
P76157684 850 mm 1205 mm 80 mm 90° Small radius Ea 880 mm 100 UHMW-PE Black UHMW-PE Black 30 mm 50 mm Not included -40÷80 °C NEW standard RS design Supply: Set of 2 pieces (upper & return) Custom curves available, please see the special form cart-icon
