878 machined turning disk
Chain turning disks
Description
Basic features
| Series: | 878 TAB |
|---|---|
| Pitch: | 38.1 mm |
| Unit of measure: | Ea |
878 machined turning disk
| Z- | Bore |
Version | Box | Type | Execution | Material | Temperature range dry | ||
|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | ||||||||
| P59300 | 34 | ○ 20 mm | Open version Drive | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59300C | 34 | ○ 20 mm | Closed version Drive | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59301 | 34 | ○ 25 mm | Open version Drive | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59301C | 34 | ○ 25 mm | Closed version Drive | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59302 | 34 | ○ 30 mm | Open version Drive | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59302C | 34 | ○ 30 mm | Closed version Drive | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59303 | 34 | ○ 35 mm | Open version Drive | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59303C | 34 | ○ 35 mm | Closed version Drive | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59304 | 34 | ○ 40 mm | Open version Drive | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59304C | 34 | ○ 40 mm | Closed version Drive | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59361 | 34 | ○ 20 mm | Open version Idler | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59362 | 34 | ○ 25 mm | Open version Idler | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59363 | 34 | ○ 30 mm | Open version Idler | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59364 | 34 | ○ 35 mm | Open version Idler | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59365 | 34 | ○ 40 mm | Open version Idler | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59371C | 34 | ○ 20 mm | Closed version Idler | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59372C | 34 | ○ 25 mm | Closed version Idler | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59373C | 34 | ○ 30 mm | Closed version Idler | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59374C | 34 | ○ 35 mm | Closed version Idler | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
| P59375C | 34 | ○ 40 mm | Closed version Idler | 1 | One-piece | Machined | PA - Polyamide composite | -40÷80 °C |
|
