83M-140M
Plastic chains
Description
Basic features
| Series: | 83M-140M |
|---|---|
| Pitch: | 35.5 mm |
| Thickness: | 4 mm |
| Surface Type: | FT - Flat Top |
| Functionality: | Side Flex |
| Unit of measure: | Meter |
83M-140M
| Width | Material | Part | Back flex radius | Sideflexing radius min | Mass | Pin material | Box | Max working load | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | |||||||||
| P12020402 | 83 mm | LFN - Low Friction Acetal (04) | P1202 | 150 mm | 150 mm | 1.35 kg/m | Stainless steel | 9,89 ft - 3,015 m | 2100 N |
|
| P12020404 | 140 mm | LFN - Low Friction Acetal (04) | P1202 | 150 mm | 250 mm | 2.1 kg/m | Stainless steel | 9,89 ft - 3,015 m | 2100 N |
|
