600 Standard
Modular Belts
Description
Basic features
| Series: | 600 |
|---|---|
| Pitch: | 31.75 mm |
| Thickness: | 12.7 mm |
| Increments: | 85 mm |
| Surface Type: | FT - Flat Top |
| Functionality: | Side-Flexing |
| Unit of measure: | Meter |
600 Standard
| Width | Material | Version | Part | Back flex radius | Max working load | Mass | Pin material | Fixation | Box | Temperature range dry | Temperature range wet | Supplementary informations | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | |||||||||||||
| P5421010255A | 255 mm (10,04") | LFA - Low friction acetal (01) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 850mm Open Surface 29,5 % |
|
| P5421010255B | 255 mm (10,04") | LFA - Low friction acetal (01) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1020 mm Open Surface 29,5 % |
|
| P5421010255C | 255 mm (10,04") | LFA - Low friction acetal (01) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1190mm Open Surface 29,5 % |
|
| P5421010255D | 255 mm (10,04") | LFA - Low friction acetal (01) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 680 mm Open Surface 29,5 % |
|
| P5421010340A | 340 mm (13,39") | LFA - Low friction acetal (01) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421010340B | 340 mm (13,39") | LFA - Low friction acetal (01) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1190mm Open Surface 29,5 % |
|
| P5421010340C | 340 mm (13,39") | LFA - Low friction acetal (01) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1190mm Open Surface 29,5 % |
|
| P5421010340D | 340 mm (13,39") | LFA - Low friction acetal (01) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 680 mm Open Surface 29,5 % |
|
| P5421010425A | 425 mm (16,73") | LFA - Low friction acetal (01) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421010425B | 425 mm (16,73") | LFA - Low friction acetal (01) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1530 mm Open Surface 29,5 % |
|
| P5421010425C | 425 mm (16,73") | LFA - Low friction acetal (01) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1360 mm Open Surface 29,5 % |
|
| P5421010425D | 425 mm (16,73") | LFA - Low friction acetal (01) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1020 mm Open Surface 29,5 % |
|
| P5421010510A | 510 mm (20,08") | LFA - Low friction acetal (01) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421010510B | 510 mm (20,08") | LFA - Low friction acetal (01) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 510 mm Open Surface 29,5 % |
|
| P5421010510C | 510 mm (20,08") | LFA - Low friction acetal (01) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1360 mm Open Surface 29,5 % |
|
| P5421010510D | 510 mm (20,08") | LFA - Low friction acetal (01) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1190mm Open Surface 29,5 % |
|
| P5421010595A | 595 mm (23,43") | LFA - Low friction acetal (01) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421010595B | 595 mm (23,43") | LFA - Low friction acetal (01) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 850mm Open Surface 29,5 % |
|
| P5421010595C | 595 mm (23,43") | LFA - Low friction acetal (01) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1530 mm Open Surface 29,5 % |
|
| P5421010595D | 595 mm (23,43") | LFA - Low friction acetal (01) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1190mm Open Surface 29,5 % |
|
| P5421010680A | 680 mm (26,77") | LFA - Low friction acetal (01) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421010680B | 680 mm (26,77") | LFA - Low friction acetal (01) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 850mm Open Surface 29,5 % |
|
| P5421010680C | 680 mm (26,77") | LFA - Low friction acetal (01) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1530 mm Open Surface 29,5 % |
|
| P5421010680D | 680 mm (26,77") | LFA - Low friction acetal (01) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1360 mm Open Surface 29,5 % |
|
| P5421010765A | 765 mm (30,12") | LFA - Low friction acetal (01) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421010765B | 765 mm (30,12") | LFA - Low friction acetal (01) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1020 mm Open Surface 29,5 % |
|
| P5421010765C | 765 mm (30,12") | LFA - Low friction acetal (01) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1530 mm Open Surface 29,5 % |
|
| P5421010765D | 765 mm (30,12") | LFA - Low friction acetal (01) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1530 mm Open Surface 29,5 % |
|
| P5421010850A | 850 mm (33,46") | LFA - Low friction acetal (01) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421010850B | 850 mm (33,46") | LFA - Low friction acetal (01) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1530 mm Open Surface 29,5 % |
|
| P5421010850C | 850 mm (33,46") | LFA - Low friction acetal (01) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1700 mm Open Surface 29,5 % |
|
| P5421010850D | 850 mm (33,46") | LFA - Low friction acetal (01) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1700 mm Open Surface 29,5 % |
|
| P5421230255A | 255 mm (10,04") | LFB - Low friction acetal (Blue) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421230255B | 255 mm (10,04") | LFB - Low friction acetal (Blue) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1700 mm Open Surface 29,5 % |
|
| P5421230255C | 255 mm (10,04") | LFB - Low friction acetal (Blue) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 680 mm Open Surface 29,5 % |
|
| P5421230255D | 255 mm (10,04") | LFB - Low friction acetal (Blue) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 510 mm Open Surface 29,5 % |
|
| P5421230340A | 340 mm (13,39") | LFB - Low friction acetal (Blue) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421230340B | 340 mm (13,39") | LFB - Low friction acetal (Blue) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 850mm Open Surface 29,5 % |
|
| P5421230340C | 340 mm (13,39") | LFB - Low friction acetal (Blue) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 850mm Open Surface 29,5 % |
|
| P5421230340D | 340 mm (13,39") | LFB - Low friction acetal (Blue) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 680 mm Open Surface 29,5 % |
|
| P5421230425A | 425 mm (16,73") | LFB - Low friction acetal (Blue) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421230425B | 425 mm (16,73") | LFB - Low friction acetal (Blue) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1020 mm Open Surface 29,5 % |
|
| P5421230425C | 425 mm (16,73") | LFB - Low friction acetal (Blue) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 850mm Open Surface 29,5 % |
|
| P5421230425D | 425 mm (16,73") | LFB - Low friction acetal (Blue) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1020 mm Open Surface 29,5 % |
|
| P5421230510A | 510 mm (20,08") | LFB - Low friction acetal (Blue) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421230510B | 510 mm (20,08") | LFB - Low friction acetal (Blue) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1190mm Open Surface 29,5 % |
|
| P5421230510C | 510 mm (20,08") | LFB - Low friction acetal (Blue) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 850mm Open Surface 29,5 % |
|
| P5421230510D | 510 mm (20,08") | LFB - Low friction acetal (Blue) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1190mm Open Surface 29,5 % |
|
| P5421230595A | 595 mm (23,43") | LFB - Low friction acetal (Blue) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421230595B | 595 mm (23,43") | LFB - Low friction acetal (Blue) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1530 mm Open Surface 29,5 % |
|
| P5421230595C | 595 mm (23,43") | LFB - Low friction acetal (Blue) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1190mm Open Surface 29,5 % |
|
| P5421230595D | 595 mm (23,43") | LFB - Low friction acetal (Blue) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1360 mm Open Surface 29,5 % |
|
| P5421230680A | 680 mm (26,77") | LFB - Low friction acetal (Blue) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | - |
|
| P5421230680B | 680 mm (26,77") | LFB - Low friction acetal (Blue) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 510 mm Open Surface 29,5 % |
|
| P5421230680C | 680 mm (26,77") | LFB - Low friction acetal (Blue) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1700 mm Open Surface 29,5 % |
|
| P5421230680D | 680 mm (26,77") | LFB - Low friction acetal (Blue) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1530 mm Open Surface 29,5 % |
|
| P5421230765A | 765 mm (30,12") | LFB - Low friction acetal (Blue) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 680 mm Open Surface 29,5 % |
|
| P5421230765B | 765 mm (30,12") | LFB - Low friction acetal (Blue) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 850mm Open Surface 29,5 % |
|
| P5421230765C | 765 mm (30,12") | LFB - Low friction acetal (Blue) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1700 mm Open Surface 29,5 % |
|
| P5421230765D | 765 mm (30,12") | LFB - Low friction acetal (Blue) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 510 mm Open Surface 29,5 % |
|
| P5421230850A | 850 mm (33,46") | LFB - Low friction acetal (Blue) | A - No tab | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 850mm Open Surface 29,5 % |
|
| P5421230850B | 850 mm (33,46") | LFB - Low friction acetal (Blue) | B - TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 1020 mm Open Surface 29,5 % |
|
| P5421230850C | 850 mm (33,46") | LFB - Low friction acetal (Blue) | C - REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 510 mm Open Surface 29,5 % |
|
| P5421230850D | 850 mm (33,46") | LFB - Low friction acetal (Blue) | D - TAB REVERSE TAB | P5421 | 25 mm | 30000 N/m | 7.7 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Specific Curve Max. Working Load - 2500N Min. Radius 680 mm Open Surface 29,5 % |
|
