552 Flat Top Transfer
Modular Belts
Description
Basic features
| Series: | 552 |
|---|---|
| Pitch: | 25.4 mm |
| Thickness: | 12.7 mm |
| Increments: | 3" - 76,2 mm |
| Surface Type: | FT - Flat Top |
| Functionality: | Straight |
| Unit of measure: | Meter |
552 Flat Top Transfer
| Width | Material | Version | Part | Back flex radius | Mass | Pin material | Fixation | Box | Max working load | Temperature range dry | Temperature range wet | Supplementary informations | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | |||||||||||||
| P5346019450C-L | 4,5" (114,3 mm) | LFA - Low friction acetal (01) | C-L - 2 Positioners - Left | P5346 | 25 mm | 13.5 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷80 °C | -40÷65 °C | - |
|
| P5346019450C-R | 4,5" (114,3 mm) | LFA - Low friction acetal (01) | C-R - 2 Positioners - Right | P5346 | 25 mm | 13.5 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷80 °C | -40÷65 °C | Specific Max Working Load = 4800 N Total Width = 160,3 mm |
|
| P5346019750C-L | 7,5" (190,5 mm) | LFA - Low friction acetal (01) | C-L - 2 Positioners - Left | P5346 | 25 mm | 13.5 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷80 °C | -40÷65 °C | - |
|
| P5346019750C-R | 7,5" (190,5 mm) | LFA - Low friction acetal (01) | C-R - 2 Positioners - Right | P5346 | 25 mm | 13.5 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷80 °C | -40÷65 °C | - |
|
| P5346039450C-L | 4,5" (114,3 mm) | MX - Performance PBT (03) | C-L - 2 Positioners - Left | P5346 | 25 mm | 13 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷120 °C | -40÷60 °C | Specific Max Working Load = 4800 N Total Width = 160,3 mm |
|
| P5346039450C-R | 4,5" (114,3 mm) | MX - Performance PBT (03) | C-R - 2 Positioners - Right | P5346 | 25 mm | 13 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷120 °C | -40÷60 °C | - |
|
| P5346039750C-L | 7,5" (190,5 mm) | MX - Performance PBT (03) | C-L - 2 Positioners - Left | P5346 | 25 mm | 13 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷120 °C | -40÷60 °C | Specific Max Working Load = 4800 N Total Width = 160,3 mm |
|
| P5346039750C-R | 7,5" (190,5 mm) | MX - Performance PBT (03) | C-R - 2 Positioners - Right | P5346 | 25 mm | 13 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷120 °C | -40÷60 °C | - |
|
| P5346179450C-L | 4,5" (114,3 mm) | MWX - Polyamide Composite (17) | C-L - 2 Positioners - Left | P5346 | 25 mm | 14 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷104 °C | Not suitable °C | - |
|
| P5346179450C-R | 4,5" (114,3 mm) | MWX - Polyamide Composite (17) | C-R - 2 Positioners - Right | P5346 | 25 mm | 14 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷104 °C | Not suitable °C | - |
|
| P5346179750C-L | 7,5" (190,5 mm) | MWX - Polyamide Composite (17) | C-L - 2 Positioners - Left | P5346 | 25 mm | 14 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷104 °C | Not suitable °C | - |
|
| P5346179750C-R | 7,5" (190,5 mm) | MWX - Polyamide Composite (17) | C-R - 2 Positioners - Right | P5346 | 25 mm | 14 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷104 °C | Not suitable °C | - |
|
| P5346259450C-L | 4,5" (114,3 mm) | MPX - Lubricated Acetal (25) | C-L - 2 Positioners - Left | P5346 | 25 mm | 13.5 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷80 °C | -40÷65 °C | - |
|
| P5346259450C-R | 4,5" (114,3 mm) | MPX - Lubricated Acetal (25) | C-R - 2 Positioners - Right | P5346 | 25 mm | 13.5 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷80 °C | -40÷65 °C | - |
|
| P5346259750C-L | 7,5" (190,5 mm) | MPX - Lubricated Acetal (25) | C-L - 2 Positioners - Left | P5346 | 25 mm | 13.5 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷80 °C | -40÷65 °C | - |
|
| P5346259750C-R | 7,5" (190,5 mm) | MPX - Lubricated Acetal (25) | C-R - 2 Positioners - Right | P5346 | 25 mm | 13.5 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | - N/m | -40÷80 °C | -40÷65 °C | - |
|
