520 Heavy Duty Flat Top
Modular Belts
Description
Description
Thanks to the robust and reliable design, the 520 Heavy Duty has improved strength and stability compared to our traditional 520 series.
The improved design provides an even better support compared to existing sytems for optimized product stability.
Easy, fixed sprocket positions ensures also an optimum belt-sprocket engagement.
Basic features
| Series: | 520 |
|---|---|
| Pitch: | 12.7 mm |
| Thickness: | 8.7 mm |
| Increments: | 85 mm |
| Surface Type: | FT - Flat Top |
| Functionality: | Straight |
| Unit of measure: | Meter |
520 Heavy Duty Flat Top
| Width | Material | Version | Part | Back flex radius | Max working load | Mass | Pin material | Fixation | Box | Temperature range dry | Temperature range wet | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | ||||||||||||
| P5211010085A | 85 mm (3,35") | LFA - Low friction acetal (01) | A - No positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211010085B | 85 mm (3,35") | LFA - Low friction acetal (01) | B - 1 Positioner | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211010085C | 85 mm (3,35") | LFA - Low friction acetal (01) | C - 2 Positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211010170A | 170 mm (6,69") | LFA - Low friction acetal (01) | A - No positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211010170B | 170 mm (6,69") | LFA - Low friction acetal (01) | B - 1 Positioner | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211010170C | 170 mm (6,69") | LFA - Low friction acetal (01) | C - 2 Positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211010255A | 255 mm (10,04") | LFA - Low friction acetal (01) | A - No positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211010255B | 255 mm (10,04") | LFA - Low friction acetal (01) | B - 1 Positioner | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211010255C | 255 mm (10,04") | LFA - Low friction acetal (01) | C - 2 Positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211010340A | 340 mm (13,39") | LFA - Low friction acetal (01) | A - No positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010340B | 340 mm (13,39") | LFA - Low friction acetal (01) | B - 1 Positioner | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010340C | 340 mm (13,39") | LFA - Low friction acetal (01) | C - 2 Positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010425A | 425 mm (16,73") | LFA - Low friction acetal (01) | A - No positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010425B | 425 mm (16,73") | LFA - Low friction acetal (01) | B - 1 Positioner | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010425C | 425 mm (16,73") | LFA - Low friction acetal (01) | C - 2 Positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010510A | 510 mm (20,08") | LFA - Low friction acetal (01) | A - No positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010510B | 510 mm (20,08") | LFA - Low friction acetal (01) | B - 1 Positioner | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010510C | 510 mm (20,08") | LFA - Low friction acetal (01) | C - 2 Positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010595A | 595 mm (23,43") | LFA - Low friction acetal (01) | A - No positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010595B | 595 mm (23,43") | LFA - Low friction acetal (01) | B - 1 Positioner | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010595C | 595 mm (23,43") | LFA - Low friction acetal (01) | C - 2 Positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010680A | 680 mm (26,77") | LFA - Low friction acetal (01) | A - No positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010680B | 680 mm (26,77") | LFA - Low friction acetal (01) | B - 1 Positioner | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211010680C | 680 mm (26,77") | LFA - Low friction acetal (01) | C - 2 Positioners | P5211 | 10 mm | 25500 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211030085A | 85 mm (3,35") | MX - Performance PBT (03) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211030085B | 85 mm (3,35") | MX - Performance PBT (03) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211030085C | 85 mm (3,35") | MX - Performance PBT (03) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211030170A | 170 mm (6,69") | MX - Performance PBT (03) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211030170B | 170 mm (6,69") | MX - Performance PBT (03) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211030170C | 170 mm (6,69") | MX - Performance PBT (03) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211030255A | 255 mm (10,04") | MX - Performance PBT (03) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211030255B | 255 mm (10,04") | MX - Performance PBT (03) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211030255C | 255 mm (10,04") | MX - Performance PBT (03) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211030340A | 340 mm (13,39") | MX - Performance PBT (03) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030340B | 340 mm (13,39") | MX - Performance PBT (03) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030340C | 340 mm (13,39") | MX - Performance PBT (03) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030425A | 425 mm (16,73") | MX - Performance PBT (03) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030425B | 425 mm (16,73") | MX - Performance PBT (03) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030425C | 425 mm (16,73") | MX - Performance PBT (03) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030510A | 510 mm (20,08") | MX - Performance PBT (03) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030510B | 510 mm (20,08") | MX - Performance PBT (03) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030510C | 510 mm (20,08") | MX - Performance PBT (03) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030595A | 595 mm (23,43") | MX - Performance PBT (03) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030595B | 595 mm (23,43") | MX - Performance PBT (03) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030595C | 595 mm (23,43") | MX - Performance PBT (03) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030680A | 680 mm (26,77") | MX - Performance PBT (03) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030680B | 680 mm (26,77") | MX - Performance PBT (03) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211030680C | 680 mm (26,77") | MX - Performance PBT (03) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211250085A | 85 mm (3,35") | MPX - Lubricated Acetal (25) | A - No positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211250085B | 85 mm (3,35") | MPX - Lubricated Acetal (25) | B - 1 Positioner | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211250085C | 85 mm (3,35") | MPX - Lubricated Acetal (25) | C - 2 Positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211250170A | 170 mm (6,69") | MPX - Lubricated Acetal (25) | A - No positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211250170B | 170 mm (6,69") | MPX - Lubricated Acetal (25) | B - 1 Positioner | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211250170C | 170 mm (6,69") | MPX - Lubricated Acetal (25) | C - 2 Positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211250255A | 255 mm (10,04") | MPX - Lubricated Acetal (25) | A - No positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211250255B | 255 mm (10,04") | MPX - Lubricated Acetal (25) | B - 1 Positioner | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211250255C | 255 mm (10,04") | MPX - Lubricated Acetal (25) | C - 2 Positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C |
|
| P5211250340A | 340 mm (13,39") | MPX - Lubricated Acetal (25) | A - No positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250340B | 340 mm (13,39") | MPX - Lubricated Acetal (25) | B - 1 Positioner | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250340C | 340 mm (13,39") | MPX - Lubricated Acetal (25) | C - 2 Positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250425A | 425 mm (16,73") | MPX - Lubricated Acetal (25) | A - No positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250425B | 425 mm (16,73") | MPX - Lubricated Acetal (25) | B - 1 Positioner | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250425C | 425 mm (16,73") | MPX - Lubricated Acetal (25) | C - 2 Positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250510A | 510 mm (20,08") | MPX - Lubricated Acetal (25) | A - No positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250510B | 510 mm (20,08") | MPX - Lubricated Acetal (25) | B - 1 Positioner | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250510C | 510 mm (20,08") | MPX - Lubricated Acetal (25) | C - 2 Positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250595A | 595 mm (23,43") | MPX - Lubricated Acetal (25) | A - No positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250595B | 595 mm (23,43") | MPX - Lubricated Acetal (25) | B - 1 Positioner | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250595C | 595 mm (23,43") | MPX - Lubricated Acetal (25) | C - 2 Positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250680A | 680 mm (26,77") | MPX - Lubricated Acetal (25) | A - No positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250680B | 680 mm (26,77") | MPX - Lubricated Acetal (25) | B - 1 Positioner | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211250680C | 680 mm (26,77") | MPX - Lubricated Acetal (25) | C - 2 Positioners | P5211 | 10 mm | 25000 N/m | 7.8 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C |
|
| P5211300085A | 85 mm (3,35") | PFX - Extra Performance PBT (30) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211300085B | 85 mm (3,35") | PFX - Extra Performance PBT (30) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211300085C | 85 mm (3,35") | PFX - Extra Performance PBT (30) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211300170A | 170 mm (6,69") | PFX - Extra Performance PBT (30) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211300170B | 170 mm (6,69") | PFX - Extra Performance PBT (30) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211300170C | 170 mm (6,69") | PFX - Extra Performance PBT (30) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211300255A | 255 mm (10,04") | PFX - Extra Performance PBT (30) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211300255B | 255 mm (10,04") | PFX - Extra Performance PBT (30) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211300255C | 255 mm (10,04") | PFX - Extra Performance PBT (30) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C |
|
| P5211300340A | 340 mm (13,39") | PFX - Extra Performance PBT (30) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300340B | 340 mm (13,39") | PFX - Extra Performance PBT (30) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300340C | 340 mm (13,39") | PFX - Extra Performance PBT (30) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300425A | 425 mm (16,73") | PFX - Extra Performance PBT (30) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300425B | 425 mm (16,73") | PFX - Extra Performance PBT (30) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300425C | 425 mm (16,73") | PFX - Extra Performance PBT (30) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300510A | 510 mm (20,08") | PFX - Extra Performance PBT (30) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300510B | 510 mm (20,08") | PFX - Extra Performance PBT (30) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300510C | 510 mm (20,08") | PFX - Extra Performance PBT (30) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300595A | 595 mm (23,43") | PFX - Extra Performance PBT (30) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300595B | 595 mm (23,43") | PFX - Extra Performance PBT (30) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300595C | 595 mm (23,43") | PFX - Extra Performance PBT (30) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300680A | 680 mm (26,77") | PFX - Extra Performance PBT (30) | A - No positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300680B | 680 mm (26,77") | PFX - Extra Performance PBT (30) | B - 1 Positioner | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
| P5211300680C | 680 mm (26,77") | PFX - Extra Performance PBT (30) | C - 2 Positioners | P5211 | 10 mm | 20000 N/m | 7.5 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C |
|
