520 Grip Top Side Indent
Modular Belts
Description
Description
Modular belt with over-molded high-grip rubber, for inclines, declines or acceleration applications, guaranteeing high performances and superior durability.
Basic features
| Series: | 520 |
|---|---|
| Pitch: | 12.7 mm |
| Thickness: | 8.7 mm |
| Increments: | 85 mm |
| Surface Type: | GT - Grip Top |
| Functionality: | Straight |
| Unit of measure: | Meter |
520 Grip Top Side Indent
| Width | Material | Version | Part | Back flex radius | Max working load | Mass | Pin material | Fixation | Box | Temperature range dry | Temperature range wet | Supplementary informations | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Code | Actions | |||||||||||||
| P5205010255A | 255 mm (10,04") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205010255B | 255 mm (10,04") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010255C | 255 mm (10,04") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 10 ft - 3,048 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010340A | 340 mm (13,39") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | - |
|
| P5205010340B | 340 mm (13,39") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010340C | 340 mm (13,39") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010425A | 425 mm (16,73") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | - |
|
| P5205010425B | 425 mm (16,73") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010425C | 425 mm (16,73") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 5 ft - 1,524 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010510A | 510 mm (20,08") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | - |
|
| P5205010510B | 510 mm (20,08") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010510C | 510 mm (20,08") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010595A | 595 mm (23,43") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | - |
|
| P5205010595B | 595 mm (23,43") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010595C | 595 mm (23,43") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010680A | 680 mm (26,77") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | - |
|
| P5205010680B | 680 mm (26,77") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010680C | 680 mm (26,77") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010765A | 765 mm (30,12") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | - |
|
| P5205010765B | 765 mm (30,12") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010765C | 765 mm (30,12") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010850A | 850 mm (33,46") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010850B | 850 mm (33,46") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010850C | 850 mm (33,46") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010935A | 935 mm (36,81") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010935B | 935 mm (36,81") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205010935C | 935 mm (36,81") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 3,33 ft - 1,016 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011020A | 1020 mm (40,16") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011020B | 1020 mm (40,16") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011020C | 1020 mm (40,16") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011105A | 1105 mm (43,50") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011105B | 1105 mm (43,50") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011105C | 1105 mm (43,50") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011190A | 1190 mm (46,85") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011190B | 1190 mm (46,85") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011190C | 1190 mm (46,85") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011275A | 1275 mm (50,20") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011275B | 1275 mm (50,20") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011275C | 1275 mm (50,20") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011360A | 1360 mm (53,54") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011360B | 1360 mm (53,54") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011360C | 1360 mm (53,54") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011445A | 1445 mm (56,89") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011445B | 1445 mm (56,89") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011445C | 1445 mm (56,89") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011530A | 1530 mm (60,24") | LFA - Low friction acetal (01) | A - No positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011530B | 1530 mm (60,24") | LFA - Low friction acetal (01) | B - 1 Positioner | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205011530C | 1530 mm (60,24") | LFA - Low friction acetal (01) | C - 2 Positioners | P5205 | 20 mm | 21500 N/m | 9 kg/m^2 | PBT white | Snap-in Clip | 2,5 ft - 0,762 m | -40÷80 °C | -40÷65 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205020255A | 255 mm (10,04") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 10 ft - 3,048 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205020255B | 255 mm (10,04") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 10 ft - 3,048 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020255C | 255 mm (10,04") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 10 ft - 3,048 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020340A | 340 mm (13,39") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 5 ft - 1,524 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205020340B | 340 mm (13,39") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 5 ft - 1,524 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020340C | 340 mm (13,39") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 5 ft - 1,524 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020425A | 425 mm (16,73") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 5 ft - 1,524 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205020425B | 425 mm (16,73") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 5 ft - 1,524 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020425C | 425 mm (16,73") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 5 ft - 1,524 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020510A | 510 mm (20,08") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205020510B | 510 mm (20,08") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020510C | 510 mm (20,08") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020595A | 595 mm (23,43") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205020595B | 595 mm (23,43") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020595C | 595 mm (23,43") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020680A | 680 mm (26,77") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205020680B | 680 mm (26,77") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020680C | 680 mm (26,77") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020765A | 765 mm (30,12") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205020765B | 765 mm (30,12") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020765C | 765 mm (30,12") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020850A | 850 mm (33,46") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205020850B | 850 mm (33,46") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020850C | 850 mm (33,46") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020935A | 935 mm (36,81") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020935B | 935 mm (36,81") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205020935C | 935 mm (36,81") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 3,33 ft - 1,016 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021020A | 1020 mm (40,16") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021020B | 1020 mm (40,16") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021020C | 1020 mm (40,16") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021105A | 1105 mm (43,50") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021105B | 1105 mm (43,50") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021105C | 1105 mm (43,50") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021190A | 1190 mm (46,85") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021190B | 1190 mm (46,85") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021190C | 1190 mm (46,85") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021275A | 1275 mm (50,20") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021275B | 1275 mm (50,20") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021275C | 1275 mm (50,20") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021360A | 1360 mm (53,54") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021360B | 1360 mm (53,54") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021360C | 1360 mm (53,54") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021445A | 1445 mm (56,89") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021445B | 1445 mm (56,89") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021445C | 1445 mm (56,89") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021530A | 1530 mm (60,24") | PP - Polypropylene (02) | A - No positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021530B | 1530 mm (60,24") | PP - Polypropylene (02) | B - 1 Positioner | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205021530C | 1530 mm (60,24") | PP - Polypropylene (02) | C - 2 Positioners | P5205 | 20 mm | 13000 N/m | 7.5 kg/m^2 | PP Blue | Snap-in Clip | 2,5 ft - 0,762 m | 4÷80 °C | 4÷80 °C | Top Rubber- 50 ShA-Pigeon blue |
|
| P5205030255A | 255 mm (10,04") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030255B | 255 mm (10,04") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030255C | 255 mm (10,04") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 10 ft - 3,048 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030340A | 340 mm (13,39") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030340B | 340 mm (13,39") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030340C | 340 mm (13,39") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030425A | 425 mm (16,73") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030425B | 425 mm (16,73") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030425C | 425 mm (16,73") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 5 ft - 1,524 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030510A | 510 mm (20,08") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030510B | 510 mm (20,08") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030510C | 510 mm (20,08") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030595A | 595 mm (23,43") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030595B | 595 mm (23,43") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030595C | 595 mm (23,43") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030680A | 680 mm (26,77") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030680B | 680 mm (26,77") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030680C | 680 mm (26,77") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030765A | 765 mm (30,12") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030765B | 765 mm (30,12") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030765C | 765 mm (30,12") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030850A | 850 mm (33,46") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030850B | 850 mm (33,46") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030850C | 850 mm (33,46") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030935A | 935 mm (36,81") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030935B | 935 mm (36,81") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205030935C | 935 mm (36,81") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 3,33 ft - 1,016 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031020A | 1020 mm (40,16") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031020B | 1020 mm (40,16") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031020C | 1020 mm (40,16") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031105A | 1105 mm (43,50") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031105B | 1105 mm (43,50") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031105C | 1105 mm (43,50") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031190A | 1190 mm (46,85") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031190B | 1190 mm (46,85") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031190C | 1190 mm (46,85") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031275A | 1275 mm (50,20") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031275B | 1275 mm (50,20") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031275C | 1275 mm (50,20") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031360A | 1360 mm (53,54") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031360B | 1360 mm (53,54") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031360C | 1360 mm (53,54") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031445A | 1445 mm (56,89") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031445B | 1445 mm (56,89") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031445C | 1445 mm (56,89") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031530A | 1530 mm (60,24") | MX - Performance PBT (03) | A - No positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031530B | 1530 mm (60,24") | MX - Performance PBT (03) | B - 1 Positioner | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
| P5205031530C | 1530 mm (60,24") | MX - Performance PBT (03) | C - 2 Positioners | P5205 | 20 mm | 17500 N/m | 9.3 kg/m^2 | POM grey | Snap-in Clip | 2,5 ft - 0,762 m | -40÷120 °C | -40÷60 °C | Top Rubber- 50 ShA-Dark grey |
|
